Schmersal AZM 200CC-T-1P2P Solenoid Interlocks
The Schmersal AZM 200CC-T-1P2P Solenoid Interlocks (Item No: 101179701) offers a inductive working principle, Spring pulley connectiontermination, IP67 degree of protection, 32 VDC rated insulation voltage Ui. Manufactured by Schmersal under the Schmersal Solenoid Interlocks. category, this model belongs to the Schmersal AZM Series.
| Brand | Schmersal |
| Product Type | Solenoid Interlock |
| Model Number | AZM 200CC-T-1P2P |
Schmersal AZM 200CC-T-1P2P Solenoid Interlocks โ Technical Specifications
| Specification | Value |
|---|---|
| Working principle | inductive |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Gross weight | 535 g |
| Holding force FZhin accordance with EN ISO 14119 | 2,000 N |
| Latching force | 30 N |
| Actuating speed, maximum | 0.2 m/s |
| Tightening torque of the fastening screws for the housing cover, minimum | 0.7 Nm |
| Tightening torque of the fastening screws for the housing cover, maximum | 1 Nm |
| Termination | Spring pulley connection |
| Cable section, minimum | 0.25 mmยฒ |
| Cable section, maximum | 1.5 mmยฒ |
| Length of sensor | 50 mm |
| Width of sensor | 40 mm |
| Height of sensor | 220 mm |
| Degree of protection | IP67 |
| Rated insulation voltage Ui | 32 VDC |
| Rated impulse withstand voltage Uimp | 0.8 kV |
| Magnet switch-on time | 100% |
IndMALL Automation Dealing offers Schmersal Solenoid interlocks AZM 200CC-T-1P2P part no: 101179701 at unbeatable prices. The Main Technical Parameters of AZM 200CC-T-1P2P, 101179701 feature inductive safety switch, designed for durability and reliability in industrial environments. The housing is made of Glass-fibre, reinforced thermoplastic, ensuring a lightweight yet robust construction with a gross weight of 535 g. It features an Spring pulley connection system, facilitating easy installation. With dimensions of 50 mm in length, 40 mm in width, and 220 mm in height, it is compact yet highly efficient. The IP67 protection rating guarantees resistance against dust, water jets, and temporary immersion, making it suitable for demanding applications. The switch operates at a rated insulation voltage (Ui) of 32 VDC, ensuring electrical safety. Additionally, it has a rated impulse withstand voltage (Uimp) of 0.8 kV, providing high surge protection. Take the First Step with a Quote for your requirement of Solenoid interlocks. Choose us for unparalleled pricing and support over other Dealers & Distributors.
