Schmersal AZM 170-02ZRK 110VAC Solenoid Interlocks
The Schmersal AZM 170-02ZRK 110VAC Solenoid Interlocks (Item No: 101136321) offers a electromechanical working principle, IDC method of terminationtermination, IP67 degree of protection, 250 VAC rated insulation voltage Ui. Manufactured by Schmersal under the Schmersal Solenoid Interlocks. category, this model belongs to the Schmersal AZM Series.
| Brand | Schmersal |
| Product Type | Solenoid Interlocks |
| Model Number | AZM 170-02ZRK 110VAC |
Schmersal AZM 170-02ZRK 110VAC Solenoid Interlocks – Technical Specifications
| Specification | Value |
|---|---|
| Coding level according to EN ISO 14119 | Low |
| Working principle | electromechanical |
| Housing material | Plastic, glass-fibre reinforced thermoplastic, self-extinguishing |
| Gross weight | 305 g |
| Holding force FZhin accordance with EN ISO 14119 | 1,000 N |
| Latching force | 30 N |
| Positive break travel | 11 mm |
| Positive break force per NC contact, minimum | 8.5 N |
| Positive break force, minimum | 17 N |
| Actuating speed, maximum | 2 m/s |
| Mounting | Screws |
| Type of the fixing screws | 2x M5 |
| Tightening torque of the fastening screws for the housing cover, minimum | 0.7 Nm |
| Tightening torque of the fastening screws for the housing cover, maximum | 1 Nm |
| Termination | IDC method of termination |
| Cable section, minimum | 0.75 mm² |
| Cable section, maximum | 1 mm² |
| Length of sensor | 30 mm |
| Width of sensor | 90 mm |
| Height of sensor | 84 mm |
| Degree of protection | IP67 |
| Rated insulation voltage Ui | 250 VAC |
| Rated impulse withstand voltage Uimp | 4 kV |
| Thermal test current | - |
| Rated control voltage | 110 VAC |
| Required rated short-circuit current | 1,000 A |
| Electrical power consumption, maximum | 12 W |
| Switching principle | slow action, positive break NC contact |
| Maximum switching frequency | 1,000 /h |
| Material of the contacts, electrical | Silver |
| Magnet switch-on time | 100 % |
| Test pulse duration, maximum | 5 ms |
| Test pulse interval, minimum | 50 ms |
| Voltage, Utilisation category AC-15 | 230 VAC |
| Voltage, Utilisation category DC-13 | 24 VDC |
| Switching element | 2 NC contact |
| Power to unlock | Yes |
| Cable entry | 1 x M20 x 1,5 |
Call us for Schmersal Solenoid interlocks AZM 170-02ZRK 110VAC part no: 101136321 at the best rates. Technical Attributes of AZM 170-02ZRK 110VAC, 101136321 are electromechanical safety switch, designed for durability and reliability in industrial environments. The housing is made of Plastic, glass-fibre reinforced thermoplastic, self-extinguishing, ensuring a lightweight yet robust construction with a gross weight of 305 g. It features an IDC method of termination system, facilitating easy installation. With dimensions of 30 mm in length, 90 mm in width, and 84 mm in height, it is compact yet highly efficient. The IP67 protection rating guarantees resistance against dust, water jets, and temporary immersion, making it suitable for demanding applications. The switch operates at a rated insulation voltage (Ui) of 250 VAC, ensuring electrical safety. Additionally, it has a rated impulse withstand voltage (Uimp) of 4 kV, providing high surge protection. Unlock Exclusive Pricing with a Quote for your requirement of Solenoid interlocks. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
