Schmersal AZM 161CC-12/12RKA-024 Solenoid Interlock
The Schmersal AZM 161CC-12/12RKA-024 Solenoid interlocks (Item No: 101166287) offers a 4 number of safety contacts, 2,600 N holding force Fmax, maximum, IP67 degree of protection, 250 VAC rated insulation voltage Ui. Manufactured by Schmersal under the Schmersal Solenoid interlocks category, this model belongs to the Schmersal AZM Series.
| Brand | Schmersal |
| Product Type | Solenoid Interlock |
| Model Number | AZM 161CC-12/12RKA-024 |
Schmersal AZM 161CC-12/12RKA-024 Solenoid Interlock β Technical Specifications
| Specification | Value |
|---|---|
| Working principle | electromechanical |
| Housing material | Plastic, glass-fibre reinforced thermoplastic, self-extinguishing |
| Gross weight | 458 g |
| Number of safety contacts | 4 |
| B10D Normally-open contact (NO) | 1,000,000 Operations |
| Holding force Fmax, maximum | 2,600 N |
| Latching force | 30 N |
| Positive break travel | 10 mm |
| Positive break force, minimum | 20 N |
| Actuating speed, maximum | 2 m/s |
| Mounting | Screws |
| Type of the fixing screws | 3x M5 |
| Type of the screw head | Flat head screw |
| Cable entry | 4 x M16 x 1,5 |
| Termination | Cage clamps |
| Cable section, minimum | 0.25 mmΒ² |
| Cable section, maximum | 1.5 mmΒ² |
| Allowed type of cable | solid single-wire solid multi-wire flexible |
| Length of sensor | 30 mm |
| Width of sensor | 130 mm |
| Height of sensor | 90 mm |
| Degree of protection | IP67 |
| Ambient temperature | -30 ... +60 Β°C |
| Storage and transport temperature | -30 ... +85 Β°C |
| Protection class | II |
| Rated insulation voltage Ui | 250 VAC |
| Rated impulse withstand voltage Uimp | 4 kV |
| Thermal test current | 6 A |
| Rated control voltage | 24 VAC/DC |
| Required rated short-circuit current | 1,000 A |
| Electrical power consumption, maximum | 10 W |
| Switching element | NO contact, NC contact |
| Switching principle | slow action, positive break NC contact |
| Maximum switching frequency | 1,000 /h |
| Material of the contacts, electrical | Silver |
| Magnet switch-on time | 100 % |
| Test pulse duration, maximum | 5 ms |
| Test pulse interval, minimum | 50 ms |
Request the best AZM 161CC-12/12RKA-024 price for Schmersal NO/NC Contacts Solenoid Interlocks (part no: 101166287). The AZM 161CC-12/12RKA-024 datasheet provides detailed specifications, including its electromechanical working principle, ensuring precise and reliable functionality. The housing is made from self-extinguishing, glass-fiber reinforced thermoplastic plastic for added safety. Mounting is secured with screws for operational stability, and cable entry is managed through 4 x M16 x 1.5 ports. Termination is achieved using cage clamps for robust connections. The sensor has a compact design, measuring 90 mm in both length and height, making it ideal for installations with limited space. It operates on a rated control voltage of 24 VAC/DC and uses a slow-action, positive break NC contact switching principle for dependable performance. Secure a quote today for your AZM 161CC-12/12RKA-024 needs and experience our competitive pricing and dedicated support that exceeds other traders. Download the AZM 161CC-12/12RKA-024 pdf for full technical details.
