Schmersal AZ201CC-T-1P2P Safety Switch with Separate Actuator
The Schmersal AZ201CC-T-1P2P Safety switch with separate actuator (Item No: 103015814) offers a RFID, 125 kHz working principle, 2 number of safety contacts, IP66, IP67 degree of protection, 32 VDC rated insulation voltage Ui. Manufactured by Schmersal under the Schmersal Safety switch with separate actuator. category, this model belongs to the Schmersal AZ Series.
| Brand | Schmersal |
| Product Type | Safety Switch with Separate Actuator |
| Model Number | AZ201CC-T-1P2P |
Schmersal AZ201CC-T-1P2P Safety Switch with Separate Actuator β Technical Specifications
| Specification | Value |
|---|---|
| Working principle | RFID, 125 kHz |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Number of safety contacts | 2 |
| B10D Normally-open contact (NO) | - |
| Latching force | - |
| Actuating speed, maximum | 0.2 m/s |
| Type of the fixing screws | 2x M6 |
| Termination | Spring pulley connection |
| Cable section, minimum | 0.25 mmΒ² |
| Cable section, maximum | 1.5 mmΒ² |
| Allowed type of cable | solid single-wire solid multi-wire flexible |
| Length of sensor | 50 mm |
| Width of sensor | 40 mm |
| Height of sensor | 220 mm |
| Degree of protection | IP66, IP67 |
| Ambient temperature | -25 ... +70 Β°C |
| Storage and transport temperature | -25 ... +85 Β°C |
| Rated insulation voltage Ui | 32 VDC |
| Rated impulse withstand voltage Uimp | 0.8 kV |
| Required rated short-circuit current | 100 A |
| Gross weight | 392 g |
Reach Us by Email for Schmersal 220 mm Height Safety Switch AZ201CC-T-1P2P part no: 103015814 at Discounted Rates. Key Technical Features of AZ201CC-T-1P2P, 103015814 are RFID, 125 kHz working principle. The switch features a robust housing made of Glass-fibre, reinforced thermoplastic ensuring durability in industrial environments. It comes with 2 safety contacts, with a B10D rating of for normally-closed (NC) contacts and - for normally-open (NO) contacts. The switch provides a latching force of - and is mounted using with secure Spring pulley connection for termination. It operates at a rated insulation voltage of 32 VDC and includes switching elements, with a maximum switching frequency of . The switch is protected with IP66, IP67 ratings, making it suitable for harsh conditions, and can operate in ambient temperatures ranging from -25 ... +70 Β°C. Navigate Your Needs with a Quote for your requirement of Schmersal 220 mm Height Safety Switch. Our pricing and support are unrivaled, especially when compared to other Competitors.
