Schmersal AZ 415-11/11ZPK-M20 Safety Switch with Separate Actuator
The Schmersal AZ 415-11/11ZPK-M20 Safety switch with separate actuator (Item No: 101154000) offers a Screw terminals M20 x 1.5 termination, 1 number of safety contacts, IP67 degree of protection, NO contact, NC contact switching element. Manufactured by Schmersal under the Schmersal Safety switch with separate actuator. category, this model belongs to the Schmersal AZ Series.
| Brand | Schmersal |
| Product Type | Safety Switch with Separate Actuator |
| Model Number | AZ 415-11/11ZPK-M20 |
Schmersal AZ 415-11/11ZPK-M20 Safety Switch with Separate Actuator โ Technical Specifications
| Specification | Value |
|---|---|
| Housing material | Aluminium |
| Number of safety contacts | 1 |
| B10D Normally-closed contact (NC) | 2,000,000 Operations |
| B10D Normally-open contact (NO) | - |
| Latching force | - |
| Positive break travel | 3.8 mm |
| Positive break force, minimum | 31 N |
| Actuating speed, maximum | 0.2 m/s |
| Termination | Screw terminals M20 x 1.5 |
| Cable section, minimum | 2 x 0.75 mmยฒ |
| Cable section, maximum | 2 x 1.5 mmยฒ |
| Length of sensor | 46.5 mm |
| Width of sensor | 84.6 mm |
| Height of sensor | 103.6 mm |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +70 ยฐC |
| Rated insulation voltage Ui | 250 VAC |
| Rated impulse withstand voltage Uimp | 4 kV |
| Thermal test current | 6 A |
| Switching element | NO contact, NC contact |
| Switching principle | Slow action |
| Material of the contacts, electrical | Silver |
| Gross weight | 495 g |
Please speak to our Technical Engineer for Schmersal Safety Switch with 46.5 mm Lenght AZ 415-11/11ZPK-M20 part no: 101154000 at attractive prices. Technical Specs Summary of AZ 415-11/11ZPK-M20, 101154000 includes working principle. The switch features a robust housing made of Aluminium ensuring durability in industrial environments. It comes with 1 safety contacts, with a B10D rating of 2,000,000 Operations for normally-closed (NC) contacts and - for normally-open (NO) contacts. The switch provides a latching force of - and is mounted using with secure Screw terminals M20 x 1.5 for termination. It operates at a rated insulation voltage of 250 VAC and includes NO contact, NC contact switching elements, with a maximum switching frequency of . The switch is protected with IP67 ratings, making it suitable for harsh conditions, and can operate in ambient temperatures ranging from -25 ... +70 ยฐC. Match Your Needs with a Quote for your requirement of Schmersal Safety Switch with 46.5 mm Lenght. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
