Schmersal AZ 3350-03ZK-U270 Safety Switch with Separate Actuator
The Schmersal AZ 3350-03ZK-U270 Safety switch with separate actuator (Item No: 101177188) offers a Electromechanical working principle, 3 number of safety contacts, IP67 degree of protection, Opener (NC) switching element. Manufactured by Schmersal under the Schmersal Safety switch with separate actuator. category, this model belongs to the Schmersal AZ Series.
| Brand | Schmersal |
| Product Type | Safety Switch with Separate Actuator |
| Model Number | AZ 3350-03ZK-U270 |
Schmersal AZ 3350-03ZK-U270 Safety Switch with Separate Actuator – Technical Specifications
| Specification | Value |
|---|---|
| Working principle | Electromechanical |
| Housing material | Aluminium |
| Number of safety contacts | 3 |
| Number of cable glands | 1 |
| B10D Normally-closed contact (NC) | 2,000,000 Operations |
| B10D Normally-open contact (NO) | - |
| Latching force | - |
| Positive break travel | 10.7 mm |
| Positive break force per NC contact, minimum | 5 N |
| Actuating speed, maximum | 0.2 m/s |
| Mounting | Screws |
| Termination | Screw terminals, Screw terminals M20 x 1.5 |
| Cable entry | 1 x M20 |
| Cable section, minimum | 0.75 mm² |
| Cable section, maximum | 2.5 mm² |
| Allowed type of cable | solid single-wire solid multi-wire flexible |
| Length of sensor | 38 mm |
| Width of sensor | 40.5 mm |
| Height of sensor | 114 mm |
| Degree of protection | IP67 |
| Ambient temperature | -30 ... +90 °C |
| Storage and transport temperature | -40 ... +90 °C |
| Rated insulation voltage Ui | 250 VAC |
| Rated impulse withstand voltage Uimp | 4 kV |
| Thermal test current | 10 A |
| Required rated short-circuit current | 1,000 A |
| Switching element | Opener (NC) |
| Switching principle | Slow action |
| Maximum switching frequency | 1,200 /h |
| Material of the contacts, electrical | Silver |
| Gross weight | 230 g |
Obtain a Quote for Schmersal 40.5 mm Width Safety Switch AZ 3350-03ZK-U270 part no: 101177188 at economical prices. Specifications Overview for AZ 3350-03ZK-U270, 101177188 reveals Electromechanical working principle. The switch features a robust housing made of Aluminium ensuring durability in industrial environments. It comes with 3 safety contacts, with a B10D rating of 2,000,000 Operations for normally-closed (NC) contacts and - for normally-open (NO) contacts. The switch provides a latching force of - and is mounted using Screws with secure Screw terminals, Screw terminals M20 x 1.5 for termination. It operates at a rated insulation voltage of 250 VAC and includes Opener (NC) switching elements, with a maximum switching frequency of 1,200 /h. The switch is protected with IP67 ratings, making it suitable for harsh conditions, and can operate in ambient temperatures ranging from -30 ... +90 °C.Take the First Step with a Quote for your requirement of Schmersal 40.5 mm Width Safety Switch. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
