Schmersal AZ 17-11ZK Safety Switch with Separate Actuator
The Schmersal AZ 17-11ZK Safety switch with separate actuator (Item No: 131121960) offers a Electromechanical working principle, 1 number of safety contacts, IP67 degree of protection, 1 NO contact, 1 NC contacts switching element. Manufactured by Schmersal under the Schmersal Safety switch with separate actuator. category, this model belongs to the Schmersal AZ Series.
| Brand | Schmersal |
| Product Type | Safety Switch with Separate Actuator |
| Model Number | AZ 17-11ZK |
Schmersal AZ 17-11ZK Safety Switch with Separate Actuator β Technical Specifications
| Specification | Value |
|---|---|
| Working principle | Electromechanical |
| Housing material | Plastic, glass-fibre reinforced thermoplastic, self-extinguishing |
| Number of safety contacts | 1 |
| Number of cable glands | 1 |
| B10D Normally-closed contact (NC) | 2,000,000 Operations |
| B10D Normally-open contact (NO) | 1,000,000 Operations |
| Latching force | - |
| Positive break travel | 11 mm |
| Positive break force per NC contact, minimum | 17 N |
| Actuating speed, maximum | 2 m/s |
| Mounting | Screws |
| Type of the fixing screws | 2x M5 |
| Termination | IDC method of termination |
| Cable entry | M 16 x 1.5 |
| Cable section, minimum | 0.75 mmΒ² |
| Cable section, maximum | 1 mmΒ² |
| Allowed type of cable | flexible |
| Length of sensor | 30 mm |
| Width of sensor | 30 mm |
| Height of sensor | 60 mm |
| Degree of protection | IP67 |
| Ambient temperature | -30 ... +80 Β°C |
| Storage and transport temperature | -30 ... +85 Β°C |
| Rated insulation voltage Ui | 250 VAC |
| Rated impulse withstand voltage Uimp | 4 kV |
| Thermal test current | 10 A |
| Required rated short-circuit current | 1,000 A |
| Switching element | 1 NO contact, 1 NC contacts |
| Switching principle | slow action, positive break NC contact |
| Maximum switching frequency | 2,000 /h |
| Material of the contacts, electrical | Silver |
| Gross weight | 85 g |
Mail us for your needs in the Schmersal Thermoplastic Safety Switch with Universal Coding AZ 17-11ZK (Part No. 131121960) at budget-friendly prices. For detailed specifications, refer to the AZ 17-11ZK datasheet or AZ 17-11ZK pdf. The AZ 17-11ZK operates on an electromechanical working principle and features a robust housing made of plastic, glass-fibre reinforced thermoplastic, which is self-extinguishing, ensuring exceptional durability in industrial environments. The switch includes 1 safety contact, with a B10D rating of 2,000,000 operations for normally-closed (NC) contacts and 1,000,000 operations for normally-open (NO) contacts. It is mounted using screws with a secure IDC termination method for easy and reliable connections. Operating at a rated insulation voltage of 250 VAC, the switch includes 1 NO contact and 1 NC contact switching elements, with a maximum switching frequency of 2,000 operations per hour. The IP67 protection ensures that the switch is highly resistant to dust and water ingress, making it perfect for harsh conditions. It can function within an ambient temperature range of -30Β°C to +80Β°C. Customize your experience with a quote for your Schmersal AZ 17-11ZK requirements and benefit from the best AZ 17-11ZK price available. Experience the difference with our competitive pricing and superior support compared to other suppliers.
