Schmersal AZ 17-02ZI B6L Safety Switch with Separate Actuator
The Schmersal AZ 17-02ZI B6L Safety switch with separate actuator (Item No: 101122858) offers a Electromechanical working principle, 2 number of safety contacts, IP67 degree of protection, 2 NC contact switching element. Manufactured by Schmersal under the Schmersal Safety switch with separate actuator. category, this model belongs to the Schmersal AZ Series.
| Brand | Schmersal |
| Product Type | Safety Switch with Separate Actuator |
| Model Number | AZ 17-02ZI B6L |
Schmersal AZ 17-02ZI B6L Safety Switch with Separate Actuator โ Technical Specifications
| Specification | Value |
|---|---|
| Working principle | Electromechanical |
| Housing material | Plastic, glass-fibre reinforced thermoplastic, self-extinguishing |
| Number of safety contacts | 2 |
| Number of cable glands | 1 |
| B10D Normally-closed contact (NC) | 2,000,000 Operations |
| Latching force | - |
| Positive break travel | 11 mm |
| Positive break force per NC contact, minimum | 17 N |
| Positive break force, minimum | 34 N |
| Actuating speed, maximum | 2 m/s |
| Mounting | Screws |
| Type of the fixing screws | 2x M5 |
| Termination | IDC method of termination |
| Cable entry | M 16 x 1.5 |
| Cable section, minimum | 0.75 mmยฒ |
| Cable section, maximum | 1 mmยฒ |
| Allowed type of cable | flexible |
| Length of sensor | 30 mm |
| Width of sensor | 30 mm |
| Height of sensor | 85 mm |
| Degree of protection | IP67 |
| Ambient temperature | -30 ... +80 ยฐC |
| Storage and transport temperature | -30 ... +85 ยฐC |
| Rated insulation voltage Ui | 250 VAC |
| Rated impulse withstand voltage Uimp | 4 kV |
| Thermal test current | 10 A |
| Required rated short-circuit current | 1,000 A |
| Switching element | 2 NC contact |
| Switching principle | slow action, positive break NC contact |
| Maximum switching frequency | 2,000 /h |
| Material of the contacts, electrical | Silver |
| Gross weight | 100 g |
Send Your Inquiry for 8 Actuation Planes Safety Switch AZ 17-02ZI B6L part no: 101122858 with cost-effective solutions. Essential Technical Specs of AZ 17-02ZI B6L, 101122858 are Electromechanical working principle. The switch features a robust housing made of Plastic, glass-fibre reinforced thermoplastic, self-extinguishing ensuring durability in industrial environments. It comes with 2 safety contacts, with a B10D rating of 2,000,000 Operations for normally-closed (NC) contacts and for normally-open (NO) contacts. The switch provides a latching force of - and is mounted using Screws with secure IDC method of termination for termination. It operates at a rated insulation voltage of 250 VAC and includes 2 NC contact switching elements, with a maximum switching frequency of 2,000 /h. The switch is protected with IP67 ratings, making it suitable for harsh conditions, and can operate in ambient temperatures ranging from -30 ... +80 ยฐC. Capture the Best Deal with a Quote for your requirement of 8 Actuation Planes Safety Switch. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
