Schmersal AZ 16 ST1-AS RB ASI-SAW Safety Switches
The Schmersal AZ 16 ST1-AS RB ASI-SAW Safety Switches (Item No: 101167265) offers a 1,000,000 Operations mechanical life, minimum, Connector plug M12, 4-pole, (A-coding) termination, IP67 degree of protection, 32 VDC rated insulation voltage Ui. Manufactured by Schmersal under the Schmersal Safety Switches. category, this model belongs to the Schmersal AZ Series.
| Brand | Schmersal |
| Product Type | Safety switch |
| Model Number | AZ 16 ST1-AS RB ASI-SAW |
Schmersal AZ 16 ST1-AS RB ASI-SAW Safety Switches – Technical Specifications
| Specification | Value |
|---|---|
| Housing material | Plastic, glass-fibre reinforced thermoplastic, self-extinguishing |
| Reaction time, maximum | 100 ms |
| Gross weight | 130 g |
| Safety classification - Category | 1 |
| PFH value | 1.14 x 10⁻⁶ /h |
| Safety classification - Note (PFH-value) | up to max. 100,000 switching cycles/year |
| Safety Integrity Level (SIL), suitable for applications in | 1 |
| Mission time | 20 Year(s) |
| Mechanical life, minimum | 1,000,000 Operations |
| Termination | Connector plug M12, 4-pole, (A-coding) |
| Length of sensor | 30 mm |
| Width of sensor | 52 mm |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +60 °C |
| Storage and transport temperature | -25 ... +85 °C |
| Rated insulation voltage Ui | 32 VDC |
| Rated impulse withstand voltage Uimp | 0.8 kV |
| Overvoltage category | III |
| Degree of pollution | 3 |
| Current consumption | 50 mA |
| Rated operating voltage | 18 ... 31.6 VDC (Protection against polarity reversal) |
Please speak to our Technical Engineer for Schmersal Safety Switches AZ 16 ST1-AS RB ASI-SAW Item No: 101167265 at attractive prices. Technical Specs Summary of AZ 16 ST1-AS RB ASI-SAW, 101167265 includes housed in a rugged Plastic, glass-fibre reinforced thermoplastic, self-extinguishing body, this unit is designed to withstand demanding environments. It offers a maximum reaction time of 100 ms and a PFH value of 1.14 x 10⁻⁶ /h, making it highly dependable for SIL-rated systems. The control panel features an Connector plug M12, 4-pole, (A-coding) for secure and easy termination. With sensor dimensions of 30 mm in length and 52 mm in width, it fits seamlessly into various control setups. Rated for both IP67 protection, it operates efficiently in ambient temperatures from -25 ... +60 °C and endures storage conditions up to -25 ... +85 °C. It supports a rated insulation voltage Ui of 32 VDC, a rated impulse withstand voltage Uimp of 0.8 kV, and operates on 18 ... 31.6 VDC (Protection against polarity reversal). Match Your Needs with a Quote for your requirement of Safety Switches AZ 16 ST1-AS RB ASI-SAW. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
