Schmersal AZ 14-1 KU CONTACT Positive-operation Door Contacts
The Schmersal AZ 14-1 KU CONTACT Positive-operation Door Contacts (Item No: 101157701) offers a 1,000,000 Operations mechanical life, minimum, IP20 degree of protection, 500 V rated insulation voltage Ui, Opener (NC) switching element. Manufactured by Schmersal under the Schmersal Positive-operation Door Contacts. category, this model belongs to the Schmersal AZ Series.
| Brand | Schmersal |
| Product Type | Positive-operation Door Contact |
| Model Number | AZ 14-1 KU CONTACT |
Schmersal AZ 14-1 KU CONTACT Positive-operation Door Contacts β Technical Specifications
| Specification | Value |
|---|---|
| Housing material | Plastic, glass-fibre reinforced thermoplastic, self-extinguishing |
| Gross weight | 40 g |
| Suitable for elevators | Yes |
| Number of safety contacts | 1 |
| Standards | - |
| Mechanical life, minimum | 1,000,000 Operations |
| Positive break force, minimum | - |
| Termination | Screw terminals M20 x 1.5 |
| Degree of protection | IP20 |
| Ambient temperature | -30 ... +70 Β°C |
| Rated insulation voltage Ui | 500 V |
| Thermal test current | 6 A |
| Switching element | Opener (NC) |
| Switching principle | Self-cleaning pressure contact |
| Material of the contacts, electrical | Silver-plated Cu rivets |
| Scope of delivery | Actuator must be ordered separately. |
| Standards | EN 81-20EN 81-50 |
| Material of the housing cover | thermoplastic, self-extinguishing |
| Actuating panels | 1. bottom |
| Actuating stroke | 7 mm |
| Actuating force, approx. | 2.2 N |
| Mounting | Round holes |
| Cable entry | Wiring compartment |
| Connection technique - Notes | M4, with self-opening clamping plates |
| Width | 44 mm |
| Height | 61 mm |
| Depth | 19 mm |
Get A Quote for Schmersal Positive-operation Door Contacts AZ 14-1 KU CONTACT Item No: 101157701 at the best price. Here are the brief Technical Specifications of AZ 14-1 KU CONTACT, 101157701 are housing is made of Plastic, glass-fibre reinforced thermoplastic, self-extinguishing to enhance fire resistance. Electrical termination is achieved through robust Screw terminals M20 x 1.5 entries, ensuring secure connections in demanding environments. Rated IP20, the device provides excellent protection against dust and water ingress, making it suitable for harsh operating conditions. It operates efficiently in ambient temperatures ranging from -30 ... +70 Β°C. The control panel features a rated insulation voltage (Ui) of 500 V and supports a thermal test current of up to 6 A. The switching element is an Opener (NC), operating on an Self-cleaning pressure contact principle for precise and stable operation. Electrical contacts are made of high-quality Silver-plated Cu rivets for enhanced conductivity and long service life. It's Time to get a Quote for your requirement of Positive-operation Door Contacts AZ 14-1 KU CONTACT. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
