Schmersal AV 415-22ZPKFE 24VAC/DC Door Locking Devices
The Schmersal AV 415-22ZPKFE 24VAC/DC Door Locking Devices (Item No: 101170941) offers a Zinc-plated metal / aluminium material of the latching bolt, 2 number of safety contacts, IP67 degree of protection, 250 VAC rated insulation voltage Ui. Manufactured by Schmersal under the Schmersal Door Locking Devices . category, this model belongs to the Schmersal AV Series.
| Brand | Schmersal |
| Product Type | Door Locking Device |
| Model Number | AV 415-22ZPKFE 24VAC/DC |
Schmersal AV 415-22ZPKFE 24VAC/DC Door Locking Devices – Technical Specifications
| Specification | Value |
|---|---|
| Housing material | Aluminium |
| Material of the latching bolt | Zinc-plated metal / aluminium |
| Gross weight | 940 g |
| Number of door leafs | 1 |
| Number of safety contacts | 2 |
| Mounting | interior mounting holes |
| Width | 130 mm |
| Height | 100 mm |
| Depth | 7.5 mm |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +50 °C |
| Rated insulation voltage Ui | 250 VAC |
| Rated impulse withstand voltage Uimp | 4 kV |
| Thermal test current | 6 A |
| Utilisation category AC-15 | 2 A |
| Utilisation category DC-13 | 1 A |
| Switching element | NC contact, NO contact |
| Switching principle | Slow action |
| Material of the contacts, electrical | Silver |
Send Your Inquiry for Schmersal Door Locking Devices AV 415-22ZPKFE 24VAC/DC Item No: 101170941 with cost-effective solutions. Essential Technical Specs of AV 415-22ZPKFE 24VAC/DC, 101170941 are housing is constructed from Aluminium for long-term durability, while the latching bolt is made of solid Zinc-plated metal / aluminium, ensuring mechanical reliability. Designed for interior mounting holes, the unit features a streamlined footprint with dimensions of 130 mm in width, 100 mm in height, and 7.5 mm in depth—ideal for space-efficient installations. It operates with a rated insulation voltage (Ui) of 250 VAC and withstands impulse voltages up to 4 kV, delivering robust electrical performance. The switching element includes NC contact, NO contact, functioning on a Slow action switching principle for reliable signal control. Rated IP67, it provides basic protection against solid objects in indoor environments. The ambient temperature range is -25 ... +50 °C, making it suitable for varied industrial settings. Capture the Best Deal with a Quote for your requirement of Door Locking Devices AV 415-22ZPKFE 24VAC/DC. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
