Schmersal A-K8P-M8-S-W-2M-BK-2-X-A-4 Connector
The Schmersal A-K8P-M8-S-W-2M-BK-2-X-A-4 Connector (Item No: 103003641) offers a 2 m length of cable, PUR material of the cable mantle, IP65IP67IP68 degree of protection, 30 VDC rated operating voltage. Manufactured by Schmersal under the Schmersal Connector. category, this model belongs to the Schmersal KA Series.
| Brand | Schmersal |
| Product Type | Connector |
| Model Number | A-K8P-M8-S-W-2M-BK-2-X-A-4 |
Schmersal A-K8P-M8-S-W-2M-BK-2-X-A-4 Connector – Technical Specifications
| Specification | Value |
|---|---|
| Product type description | A-K8P-M8-S-W-2M-BK-2-X-A-4 |
| Gross weight | 120 g |
| Number of cable wires | 8 |
| Length of cable | 2 m |
| Material of the Cable mantle | PUR |
| Pin assignment - PIN 1 | White |
| Pin assignment - PIN 2 | Brown |
| Pin assignment - PIN 3 | green |
| Pin assignment - PIN 4 | yellow |
| Pin assignment - PIN 5 | Grey |
| Pin assignment - PIN 6 | Pink |
| Pin assignment - PIN 7 | Blue |
| Pin assignment - PIN 8 | red |
| Number of poles | 8 |
| Tightening torque, maximum | 0.6 Nm |
| Wire cross-section | 0.25 mm2 |
| Cable diameter | 6 mm |
| Bending radius (fixed) | 5 x Ø-cable |
| Bending radius (repeated) | 10 x Ø-cable |
| Colour of the Cable mantle | Black |
| Connector typ | Female connector, M8 |
| Design | angled |
| Connector latching | Screw locking |
| Material of the gland | Metal, CuZn, nickel-plated |
| Material of the handle | Plastic, TPU |
| Colour of the handle | Black |
| Degree of protection | IP65IP67IP68 |
| Ambient temperature (Connector) | -25 ... +85 °C |
| Ambient temperature (fixed) | -50 ... +90 °C |
| Thermal test current | 1.5 A |
| Rated operating voltage | 30 VDC |
| Operating current | 1,500 mA |
