Puls UB10.241: DIN Power Supply

Technical Specifications of Puls DIN Power Supply UB10.241:
Spec | Value |
---|---|
Brand | Puls |
Product Type | Power Supply |
Product | UB10.241 |
Puls DIN Power Supply UB10.241 Technical Specifications
Specification | Value |
---|---|
DC Input voltage | DC 24 V |
Int. current consumption (incl. charging current) | 1.3 A |
Nominal voltage | 24 Vdc |
Output current | 15 A |
Storage element | External lead acid battery |
Allowed battery size | 12 V, 3.9 to 40 Ah VRLA lead acid |
Temperature tracking of the end-of-charge voltage | manual-select |
Dimensions (WxHxD) | 49 mm x 124 mm x 117 mm |
Weight per unit (excl. packaging) | 530 g |
Mounting method | DIN rail |
Operating temp. range | -25 °C to 70 °C |
Connection method | Spring clamps |
Derating | 0.25 W/°C for >+60 °C |
Engineered for high-performance applications, the Puls UB10.241 delivers a steady 24 V DC nominal voltage with a strong 15 A output current, making it suitable for powering demanding automation loads. It operates on a DC 24 V input and consumes just 1.3 A internally, even with battery charging included. The key highlight of this model is its compatibility with external VRLA lead acid batteries ranging from 12 V, 3.9 Ah to 40 Ah, allowing users to customize backup duration based on system needs.
Unlike fully automatic charging models, the UB10.241 offers manual-select temperature tracking for the end-of-charge voltage, giving engineers more control over battery maintenance across varying ambient conditions. The unit is built with compact dimensions of 49 mm x 124 mm x 117 mm and weighs only 530 g, making it ideal for space-constrained panels. With DIN rail mounting and tool-free spring clamp connections, installation and maintenance are efficient and reliable, even in fast-paced production environments.
This model stands out with its wide operating temperature range of -25 °C to +70 °C, and incorporates thermal derating of 0.25 W/°C above 60 °C, ensuring consistent performance in both hot and cold conditions. Trusted by automation professionals and panel builders, the Puls UB10.241 is a dependable power solution for buffer applications, enabling smooth system shutdowns or transitions during power interruptions. Learn more on the official Puls UB10.241 product page.
The Puls UB10.241 is an ideal choice for automation systems where external battery-based buffering is preferred over internal solutions. It provides regulated 24 V DC output to critical components such as sensors, drives, controllers, and relays, ensuring they remain active even during brief power disturbances. This feature is essential in process industries, conveyors, and data-sensitive systems that require time to safely complete tasks before shutdown.
By allowing users to connect VRLA batteries up to 40 Ah, the UB10.241 gives flexibility to extend backup time based on system size and criticality. It's commonly used in machinery panels, automated warehouses, and safety circuits, where backup power needs to be both scalable and cost-effective. The manual temperature adjustment feature makes it particularly useful in environments with fluctuating ambient conditions—like cold storage areas or high-heat zones.
Designed to meet the real-world needs of Indian engineers and plant technicians, this model balances compact design, user control, and performance. Whether you are upgrading a legacy system or integrating a new panel, the Puls UB10.241 offers long-term reliability and protection against unexpected power loss.
