Puls TP960.241 Power Supply
The Puls TP960.241 Power Supply offers 24 Vdc, DIN rail Mounting Method, Spring clamps Connection Method, 41.1 A at 28 V output current. Manufactured by Puls under the Puls Power Supply category, this model belongs to the 3-phase system
| Brand | Puls |
| Product Type | Power Supply |
| Model Number | TP960.241 |
Puls TP960.241 Power Supply – Technical Specifications
| Specification | Value |
|---|---|
| AC Input voltage | AC 380 - 500 V (-15 %/+10 %) |
| Harmonic correction | - |
| Power factor | 0.91 |
| Input inrush current limitation | active |
| Input inrush current | - |
| External input fuse recommendation | B-16 A / C-16 A |
| Nominal voltage | 24 Vdc |
| Adjustment range | 24 - 28 V |
| Output current range | 48 - 41.1 A |
| Output current | 41.1 A at 28 V |
| Output power | 960 W |
| Derating | 12.8 W/°C for +45 to +60 °C |
| Ripple and noise voltage max. | 50 mVpp |
| Dimensions (WxHxD) | 79 mm x 124 mm x 136 mm |
| Weight per unit (excl. packaging) | 1100 g |
| Mounting method | DIN rail |
| Operating temp. range | -40 °C to 70 °C |
| Connection method | Spring clamps |
| Efficiency, typ. | 97 % |
| Power losses, typ. | 28 W |
| Housing material | Metal and plastic |
