Puls QTD20.241 Power Supply
The Puls QTD20.241 Power Supply offers 24 Vdc, DIN rail Mounting Method, Spring clamps Connection Method, 17.5 A at 28 V output current. Manufactured by Puls under the Puls Power Supply category, this model belongs to the 3-phase system
| Brand | Puls |
| Product Type | Power Supply |
| Model Number | QTD20.241 |
Puls QTD20.241 Power Supply – Technical Specifications
| Specification | Value |
|---|---|
| DC Input voltage | DC 600 V (-20 %/+40 %) |
| Harmonic correction | - |
| Power factor | - |
| Input inrush current limitation | active |
| Input inrush current | 3 A / 1.6 A |
| External input fuse recommendation | B-6 A / C-3 A |
| Nominal voltage | 24 Vdc |
| Adjustment range | 24 - 28 V |
| Output current range | 20 - 17.5 A |
| Output current | 17.5 A at 28 V |
| Output power | 480 W |
| Derating | 12 W/°C for >+60 °C |
| Ripple and noise voltage max. | 100 mVpp |
| Dimensions (WxHxD) | 65 mm x 124 mm x 127 mm |
| Weight per unit (excl. packaging) | 890 g |
| Mounting method | DIN rail |
| Operating temp. range | -25 °C to 70 °C |
| Connection method | Spring clamps |
| Efficiency, typ. | 95 % |
| Power losses, typ. | 25.5 W |
