Puls QS5.241-60 Power Supply
The Puls QS5.241-60 Power Supply offers 24 Vdc, DIN rail Mounting Method, Spring clamps Connection Method, 3.6 A at 28 V output current. Manufactured by Puls under the Puls Power Supply category, this model belongs to the 3-phase system
| Brand | Puls |
| Product Type | Power Supply |
| Model Number | QS5.241-60 |
Puls QS5.241-60 Power Supply β Technical Specifications
| Specification | Value |
|---|---|
| DC Input voltage | DC 110 V (-30 %/+40 %) |
| Harmonic correction | - |
| Power factor | - |
| Input inrush current limitation | - |
| Input inrush current | - |
| External input fuse recommendation | - |
| Nominal voltage | 24 Vdc |
| Adjustment range | 24 - 28 V |
| Output current range | 4.2 - 3.6 A |
| Output current | 3.6 A at 28 V |
| Output power | 100 W |
| Derating | - |
| Ripple and noise voltage max. | 50 mVpp |
| Dimensions (WxHxD) | 40 mm x 124 mm x 117 mm |
| Weight per unit (excl. packaging) | 640 g |
| Mounting method | DIN rail |
| Operating temp. range | -25 Β°C to 70 Β°C |
| Connection method | Spring clamps |
| Efficiency, typ. | 91.1 % |
| Power losses, typ. | 9.8 W |
