Puls QS5.241 Power Supply
The Puls QS5.241 Power Supply offers 24 Vdc, DIN rail Mounting Method, Spring clamps Connection Method, 4.5 A at 28 V output current. Manufactured by Puls under the Puls Power Supply category, this model belongs to the 3-phase system
| Brand | Puls |
| Product Type | Power Supply |
| Model Number | QS5.241 |
Puls QS5.241 Power Supply – Technical Specifications
| Specification | Value |
|---|---|
| AC Input voltage | AC 100 - 240 V (-15 %/+10 %) |
| DC Input voltage | DC 110 V - 300 V (± 20 %) |
| Harmonic correction | active |
| Power factor | 0.91 |
| Input inrush current limitation | active |
| Input inrush current | 9 A / 11 A |
| External input fuse recommendation | B-6 A / C-3 A |
| Nominal voltage | 24 Vdc |
| Adjustment range | 24 - 28 V |
| Output current range | 5 - 4.5 A |
| Output current | 4.5 A at 28 V |
| Output power | 120 W |
| Derating | 3 W/°C for >+60 °C |
| Ripple and noise voltage max. | 50 mVpp |
| Dimensions (WxHxD) | 40 mm x 124 mm x 117 mm |
| Weight per unit (excl. packaging) | 620 g |
| Mounting method | DIN rail |
| Operating temp. range | -25 °C to 70 °C |
| Connection method | Spring clamps |
| Efficiency, typ. | 92.7 % |
| Power losses, typ. | 9.4 W |
