Home Puls Power Supply QS3.241 Puls QS3.241 Power Supply The Puls QS3.241 Power Supply offers 24 Vdc, DIN rail Mounting Method, Spring clamps Connection Method, 3 A at 28 V output current. Manufactured by Puls under the Puls Power Supply category, this model belongs to the 3-phase system
Brand Puls Product Type Power Supply Model Number QS3.241
Puls QS3.241 Power Supply – Technical Specifications Specification Value AC Input voltage AC 100 - 240 V (± 15 %) DC Input voltage DC 110 V - 125 V (-20 %/+25 %) Harmonic correction - Power factor 0.47 Input inrush current limitation active Input inrush current 5 A / 10 A External input fuse recommendation B-6 A / C-6 A Nominal voltage 24 Vdc Adjustment range 24 - 28 V Output current range 3.4 - 3 A Output current 3 A at 28 V Output power 80 W Derating 2 W/°C for >+60 °C Ripple and noise voltage max. 50 mVpp Dimensions (WxHxD) 32 mm x 124 mm x 102 mm Weight per unit (excl. packaging) 440 g Mounting method DIN rail Operating temp. range -25 °C to 70 °C Connection method Spring clamps Efficiency, typ. 90 % Power losses, typ. 9.1 W
