Puls CPS20.241-60 Power Supply
The Puls CPS20.241-60 Power Supply offers 24.5 Vdc, DIN rail Mounting Method, Spring clamps Connection Method, 16.3 A at 24.5 V output current. Manufactured by Puls under the Puls Power Supply category, this model belongs to the 3-phase system
| Brand | Puls |
| Product Type | Power Supply |
| Model Number | CPS20.241-60 |
Puls CPS20.241-60 Power Supply β Technical Specifications
| Specification | Value |
|---|---|
| DC Input voltage | DC 110 V (-30 %/+40 %) |
| Harmonic correction | - |
| Power factor | - |
| Input inrush current limitation | - |
| Input inrush current | - |
| External input fuse recommendation | - |
| Nominal voltage | 24.5 Vdc |
| Adjustment range | 24.5 V |
| Output current range | 16.3 A |
| Output current | 16.3 A at 24.5 V |
| Output power | 400 W |
| Derating | - |
| Ripple and noise voltage max. | 70 mVpp |
| Dimensions (WxHxD) | 65 mm x 124 mm x 127 mm |
| Weight per unit (excl. packaging) | 980 g |
| Mounting method | DIN rail |
| Operating temp. range | -40 Β°C to 70 Β°C |
| Connection method | Spring clamps |
| Efficiency, typ. | 93.7 % |
| Power losses, typ. | 26.9 W |
