Puls CP20.245-R2 Power Supply
The Puls CP20.245-R2 Power Supply offers 24 Vdc, DIN rail Mounting Method, Plug connector Connection Method, 20 A at 24 V output current. Manufactured by Puls under the Puls Power Supply category, this model belongs to the 3-phase system
| Brand | Puls |
| Product Type | Power Supply |
| Model Number | CP20.245-R2 |
Puls CP20.245-R2 Power Supply – Technical Specifications
| Specification | Value |
|---|---|
| AC Input voltage | AC 100 - 240 V (-15 %/+10 %) |
| DC Input voltage | DC 110 V - 150 V (± 20 %) |
| Harmonic correction | active |
| Power factor | 0.98 |
| Input inrush current limitation | active |
| Input inrush current | 10 A / 4.5 A |
| External input fuse recommendation | B-10 A / C-10 A |
| Nominal voltage | 24 Vdc |
| Adjustment range | 24 V |
| Output current range | 20 A |
| Output current | 20 A at 24 V |
| Output power | 480 W |
| Derating | 12 W/°C for >+60 °C |
| Ripple and noise voltage max. | 100 mVpp |
| Dimensions (WxHxD) | 48 mm x 124 mm x 127 mm |
| Weight per unit (excl. packaging) | 850 g |
| Mounting method | DIN rail |
| Operating temp. range | -40 °C to 70 °C |
| Connection method | Plug connector |
| Efficiency, typ. | 95.2 % |
| Power losses, typ. | 24.2 W |
