Phoenix RIF-1-RSC-LDP-24DC/2X21/FG Relay Module
The Phoenix RIF-1-RSC-LDP-24DC/2X21/FG Relay Module (Part No: 2909848 ) offers a AgSnO contact material, 20.4 V DC ... 28.8 V DC (20 Β°C) input voltage range, polarized Drive, 15 ms typical response time. Manufactured by Phoenix under the Phoenix Relay Module category, this model belongs to the Phoenix PLC Series.
| Brand | Phoenix Contact |
| Product Type | Relay Module |
| Model Number | RIF-1-RSC-LDP-24DC/2X21/FG |
Phoenix RIF-1-RSC-LDP-24DC/2X21/FG Relay Module β Technical Specifications
| Specification | Value |
|---|---|
| Product type | Relay Module |
| Product family | RIFLINE complete |
| Application | Forcibly guided contacts |
| Mechanical service life | approx. 107 cycles |
| Insulation | Safe isolation between input and output |
| Overvoltage category | III |
| Pollution degree | 2 |
| Maximum power dissipation for nominal condition | 0.72 W |
| Test voltage (Winding/contact) | 4 kVrms (50 Hz, 60 s) |
| Test voltage (Changeover contact/changeover contact) | 2.5 kVrms (50 Hz, 60 s) |
| Rated surge voltage | 6 kV (Input/output) |
| Input voltage range | 20.4 V DC ... 28.8 V DC (20 Β°C) |
| Drive and function | monostable |
| Drive (polarity) | polarized |
| Typical input current at UN | 30 mA |
| Typical response time | 15 ms |
| Typical release time | 10 ms |
| Protective circuit | Freewheeling diode |
| Operating voltage display | Yellow LED |
| Contact switching type | 2 changeover contacts, forcibly actuated |
| Type of switch contact | Single contact |
| Contact material | AgSnO |
| Maximum switching voltage | 250 V AC/DC |
| Limiting continuous current | 6 A |
| Maximum inrush current | - |
| Min. switching current | - |
| Interrupting rating (ohmic load) max. | 144 W (24 V DC) |
| Switching capacity | - |
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Conductor cross section rigid | 0.5 mmΒ² ... 4 mmΒ² |
| Conductor cross section flexible | 0.5 mmΒ² ... 4 mmΒ² |
| Conductor cross section AWG | 20 ... 10 (solid) |
| Tightening torque | 0.5 Nm ... 0.6 Nm |
| Width | 16 mm |
| Height | 90 mm |
| depth | 75 mm |
| Color | gray (RAL 7042) |
| Flammability rating according to UL 94 | V2 (Housing) |
| Degree of protection (Relay) | RT I (Relay) |
| Degree of protection (Relay base) | IP20 (Relay base) |
| Ambient temperature (operation) | -25 Β°C ... 60 Β°C |
| Ambient temperature (storage/transport) | -25 Β°C ... 85 Β°C |
| Temperature | - |
| Humidity | - |
| Vibration | - |
| EMC | - |
| Enclosure | - |
| Low Voltage Directive | - |
| Electromagnetic compatibility | - |
| Standards/regulations | DIN EN 60947-5-1 |
| Mounting Type | DIN rail mounting |
| Mounting position | any |
| Contact Connection type | - |
| Output fuse | - |
| Degree of protection (Installation location) | - |
