Phoenix RIF-1-RSC-LDP-12DC/1IC Relay Module
The Phoenix RIF-1-RSC-LDP-12DC/1IC Relay Module (Part No: 1078803 ) offers a 12 V DC nominal input voltage UN, 9.6 V DC ... 16.8 V DC (20 Β°C) input voltage range, polarized Drive, 8 ms typical response time. Manufactured by Phoenix under the Phoenix Relay Module category, this model belongs to the Phoenix PLC Series.
| Brand | Phoenix Contact |
| Product Type | Relay Module |
| Model Number | RIF-1-RSC-LDP-12DC/1IC |
Phoenix RIF-1-RSC-LDP-12DC/1IC Relay Module β Technical Specifications
| Specification | Value |
|---|---|
| Product type | Relay Module |
| Product family | RIFLINE complete |
| Application | high inrush currents |
| Mechanical service life | 3x 107 cycles |
| Insulation | Safe isolation, reinforced insulation |
| Overvoltage category | III |
| Pollution degree | 2 |
| Maximum power dissipation for nominal condition | 0.41 W |
| Test voltage (Winding/contact) | 4 kV AC (50 Hz, 1 min., winding/contact) |
| Test voltage (Changeover contact/changeover contact) | - |
| Rated surge voltage | 6 kV |
| Nominal input voltage UN | 12 V DC |
| Input voltage range | 9.6 V DC ... 16.8 V DC (20 Β°C) |
| Drive and function | monostable |
| Drive (polarity) | polarized |
| Typical input current at UN | 34 mA |
| Typical response time | 8 ms |
| Typical release time | 10 ms |
| Protective circuit | Surge protection; Freewheeling diode |
| Operating voltage display | Yellow LED |
| Contact switching type | 1 N/O contact |
| Type of switch contact | Single contact |
| Contact material | AgSnO |
| Maximum switching voltage | 250 V AC/DC (The separating plate PLC-ATP should be installed for voltages larger than 250 V (L1, L2, L3) between identical terminal blocks in adjacent modules. Potential bridging is then carried out with FBST 8-PLC... or ...FBST 500...) |
| Limiting continuous current | 6 A |
| Maximum inrush current | 80 A (20 ms) |
| Min. switching current | 100 mA (12 V DC) |
| Interrupting rating (ohmic load) max. | 264 W (at 24 V DC, observe contact derating) |
| Switching capacity | - |
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Conductor cross section rigid | 0.5 mmΒ² ... 4 mmΒ² |
| Conductor cross section flexible | 0.5 mmΒ² ... 4 mmΒ² |
| Conductor cross section AWG | 20 ... 10 (solid) |
| Tightening torque | 0.5 Nm ... 0.6 Nm |
| Width | 16 mm |
| Height | 90 mm |
| depth | 75 mm |
| Color | gray (RAL 7042) |
| Flammability rating according to UL 94 | - |
| Degree of protection (Relay) | RT II (Relay) |
| Degree of protection (Relay base) | IP20 (Relay base) |
| Ambient temperature (operation) | -40 Β°C ... 70 Β°C |
| Ambient temperature (storage/transport) | -40 Β°C ... 85 Β°C |
| Temperature | - |
| Humidity | - |
| Vibration | - |
| EMC | - |
| Enclosure | - |
| Low Voltage Directive | - |
| Electromagnetic compatibility | - |
| Standards/regulations | IEC 60947-5-1 |
| Mounting Type | DIN rail mounting |
| Mounting position | any |
| Contact Connection type | - |
| Output fuse | - |
| Degree of protection (Installation location) | β₯ IP54 (Installation location) |
Please speak to our Technical Engineer for Phoenix Screw Connection Relay Module RIF-1-RSC-LDP-12DC/1IC part no: 1078803 at attractive prices. Technical Specs Summary of RIF-1-RSC-LDP-12DC/1IC, 1078803 includes Relay Module type and RIFLINE complete Product family a versatile solution for high inrush currents applications. This relay module features a mechanical service life of 3x 107 cycles, ensuring durability and reliability. With a maximum power dissipation of 0.41 W, it operates efficiently at a nominal input voltage of 12 V DC, within an input voltage range of 9.6 V DC ... 16.8 V DC (20 Β°C). The module has a typical input current of 34 mA at UN, with a response time of 8 ms and a release time of 10 ms. It is equipped with a Surge protection; Freewheeling diode for protection and includes 1 N/O contact made from Screw connection Connection method. Match Your Needs with a Quote for your requirement of Phoenix Screw Connection Relay Module. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
