Phoenix REL-SR- 24DC/2X21/FG X Single Relay
The Phoenix REL-SR- 24DC/2X21/FG X Single Relay (Part No: 1473564 ) offers a 24 V DCnominal input voltage UN, 19.2 V DC ... 26.4 V DC input voltage range, 250 V AC/DC switching voltage, - method. Manufactured by Phoenix under the Phoenix Single Relay category, this model belongs to the Phoenix REL Series.
| Brand | Phoenix Contact |
| Product Type | Single Relay |
| Model Number | REL-SR- 24DC/2X21/FG X |
Phoenix REL-SR- 24DC/2X21/FG X Single Relay β Technical Specifications
| Specification | Value |
|---|---|
| Product type | Single relay |
| Mechanical service life | approx. 107 cycles |
| Insulation | Reinforced insulation |
| Overvoltage category | III |
| Pollution degree | 2 |
| Service life electrical | - |
| Maximum power dissipation for nominal condition | 0.7 W |
| Test voltage (Winding/contact) | 4 kVrms (50 Hz, 1 min.) |
| Test voltage (Changeover contact/changeover contact) | 2.5 kVrms (50 Hz, 1 min.) |
| Rated insulation voltage | 250 V AC |
| Rated surge voltage | 6 kV |
| Nominal input voltage UN | 24 V DC |
| Input voltage range | 19.2 V DC ... 26.4 V DC |
| Drive and function | monostable |
| Drive (polarity) | non-polarized |
| Typical input current at UN | 30 mA |
| Typical response time | 10 ms |
| Coil voltage | 24 V DC |
| Status display | LED (yellow) |
| Contact switching type | 2 changeover contacts, forcibly actuated |
| Type of switch contact | Single contact |
| Contact material | AgSnO |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | - |
| Limiting continuous current | 6 A |
| Maximum inrush current | - |
| Min. switching current | - |
| Interrupting rating (ohmic load) max. | 144 W (24 V DC) |
| Connection method | - |
| Width | 12.6 mm |
| Height | 29 mm |
| Depth | 26.3 mm |
| Degree of protection | - |
| Degree of protection (Installation location) | IP54 (Installation location) |
| Ambient temperature (operation) | -25 Β°C ... 60 Β°C |
| Ambient temperature (storage/transport) | -25 Β°C ... 85 Β°C |
| Standards/regulations | EN 60947-5-1 |
| Mounting type | Plug-in mounting |
| Mounting position | any |
| Mains frequency | - |
| Typical release time range | - |
| Coil resistance | - |
| Switching capacity | - |
| Motor load according to UL 508 | - |
| Input power dissipation for UN | 0.72 W |
| 3-phase motor load | - |
| Product family | - |
| Relay type | - |
| Test voltage () | 1.5 kVrms (50 Hz, 1 min.) |
| Degree of protection (Relay) | RT II (Relay) |
| Inrush current, minimum | - |
| Non-operate voltage | - |
| Safe operate voltage | - |
| Test voltage (N/O contact / N/O contact) | - |
Ask for the Pricing of Phoenix Force-guided Contacts Safety Relay REL-SR- 24DC/2X21/FG X part no: 1473564 at unbeatable prices. Detailed Specifications of REL-SR- 24DC/2X21/FG X, 1473564 feature mechanical service life of approx. 107 cycles, designed for demanding industrial applications. The sensor operates at a nominal input voltage of 24 V DC, with an input voltage range of 19.2 V DC ... 26.4 V DC. The typical input current at UN is 30 mA with a response time of 15 ms. The sensor supports a maximum switching voltage of 250 V AC/DC, and a minimum switching voltage of -. It has a limiting continuous current of 6 A, with a maximum inrush current of -, and a minimum switching current of -. The interrupting rating for ohmic loads is 144 W (24 V DC). The connection method is via a -, with a degree of protection rated at -. The sensor operates reliably in ambient temperatures ranging from -25 Β°C ... 60 Β°C. Now's the Time to Secure a Quote for your requirement of Phoenix Force-guided Contacts Safety Relay. We're committed to offering more favorable pricing and more responsive support than other Traders.
