Phoenix REL-IR4/LDP- 24DC/4X21AU Single Relay
The Phoenix REL-IR4/LDP- 24DC/4X21AU Single Relay (Part No: 2903670 ) offers a 24 V DCnominal input voltage UN, 18.7 V DC ... 46.8 V DC (20 °C) input voltage range, 250 V AC/DC switching voltage, Plug-in connection method. Manufactured by Phoenix under the Phoenix Single Relay category, this model belongs to the Phoenix REL Series.
| Brand | Phoenix Contact |
| Product Type | Single Relay |
| Model Number | REL-IR4/LDP- 24DC/4X21AU |
Phoenix REL-IR4/LDP- 24DC/4X21AU Single Relay – Technical Specifications
| Specification | Value |
|---|---|
| Product type | Single relay |
| Mechanical service life | approx. 2x 107 cycles |
| Insulation | Basic insulation |
| Overvoltage category | II |
| Pollution degree | 2 |
| Service life electrical | see diagram |
| Maximum power dissipation for nominal condition | 1.01 W |
| Test voltage (Winding/contact) | 2.5 kVrms (50 Hz, 1 min., winding/contact) |
| Test voltage (Changeover contact/changeover contact) | 2 kVrms (50 Hz, 1 min., changeover contact/changeover contact) |
| Rated insulation voltage | 250 V AC |
| Rated surge voltage | 2.5 kV |
| Nominal input voltage UN | 24 V DC |
| Input voltage range | 18.7 V DC ... 46.8 V DC (20 °C) |
| Drive and function | monostable |
| Drive (polarity) | polarized |
| Typical input current at UN | 42 mA |
| Typical response time | 13 ms |
| Typical release time | 14 ms |
| Status display | LED (yellow) |
| Contact switching type | 4 changeover contacts |
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 5 V (At 24 mA) |
| Limiting continuous current | 6 A |
| Maximum inrush current | 16 A (20 ms, N/O contacts) |
| Min. switching current | 5 mA (at 24 V) |
| Interrupting rating (ohmic load) max. | 144 W (at 24 V DC) |
| Connection method | Plug-in connection |
| Width | 21.2 mm |
| Height | 27.5 mm |
| Depth | 35.6 mm |
| Degree of protection | RT I |
| Ambient temperature (operation) | -40 °C ... 70 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Standards/regulations | IEC 60664 |
| Mounting position | any |
| Switching capacity | 2 A (at 24 V, DC13) |
| Motor load according to UL 508 | 1/3 HP, 240 V AC |
The Phoenix Contact REL-IR4/LDP-24DC/4X21AU (Part No: 2903670) delivers stable and precise signal switching in modern automation control panels. Operating at a nominal input voltage of 24 V DC, it supports a wide range from 18.7 V to 46.8 V DC, offering flexibility for various industrial voltage environments. Built with AgNi contact material, the relay offers 4 changeover contacts and handles up to 250 V AC/DC maximum switching voltage. With a mechanical service life of 2 × 10⁷ cycles and an interrupting rating of 144 W at 24 V DC, it provides excellent longevity for repetitive operations. It supports a limiting continuous current of 6 A and manages inrush currents up to 16 A on N/O contacts, making it suitable for motor and inductive load switching. The typical input current is 42 mA, and the response time is 14 ms, ensuring fast actuation. The relay features a plug-in connection method with dimensions of 21.2 mm width, 27.5 mm height, and 35.6 mm depth, optimizing it for space-constrained enclosures. With a protection class of RT I, a yellow LED status indicator, and compliance with IEC 60664, it’s engineered for both reliability and safety in harsh environments.
