Phoenix PLC-RSC- 24DC/1/CB1-6 Relay Module
The Phoenix PLC-RSC- 24DC/1/CB1-6 Relay Module (Part No: 1328357 ) offers a 6.2 mm width, 94 mm depth, 80 mm Height, DIN rail mounting type. Manufactured by Phoenix under the Phoenix Relay Module category, this model belongs to the Phoenix PLC Series.
| Brand | Phoenix Contact |
| Product Type | Relay Module |
| Model Number | PLC-RSC- 24DC/1/CB1-6 |
Phoenix PLC-RSC- 24DC/1/CB1-6 Relay Module โ Technical Specifications
| Specification | Value |
|---|---|
| Product type | Relay Module |
| Product family | PLC-INTERFACE |
| Application | with integrated electronic circuit breaker |
| Mechanical service life | - |
| Insulation | Functional insulation |
| Overvoltage category | I |
| Pollution degree | 2 |
| Maximum power dissipation for nominal condition | < 1.6 W |
| Test voltage (Winding/contact) | - |
| Test voltage (Changeover contact/changeover contact) | - |
| Rated surge voltage | - |
| Operating voltage display | - |
| Contact switching type | - |
| Type of switch contact | - |
| Contact material | - |
| Maximum switching voltage | - |
| Limiting continuous current | - |
| Maximum inrush current | - |
| Min. switching current | - |
| Interrupting rating (ohmic load) max. | - |
| Switching capacity | - |
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Conductor cross section rigid | 0.2 mmยฒ ... 2.5 mmยฒ |
| Conductor cross section flexible | 0.2 mmยฒ ... 2.5 mmยฒ |
| Conductor cross section AWG | 30 ... 12 |
| Tightening torque | 0.45 Nm ... 0.55 Nm (Usually these terminal blocks must be supported during conductor connection (held by one hand, supported on the housing)) |
| Width | 6.2 mm |
| Height | 80 mm |
| depth | 94 mm |
| Color | - |
| Flammability rating according to UL 94 | - |
| Degree of protection (Relay) | - |
| Degree of protection (Relay base) | - |
| Ambient temperature (operation) | -25 ยฐC ... 55 ยฐC (Observe derating in the connected state) |
| Ambient temperature (storage/transport) | -40 ยฐC ... 70 ยฐC |
| Temperature | - |
| Humidity | - |
| Vibration | - |
| EMC | - |
| Enclosure | - |
| Low Voltage Directive | - |
| Electromagnetic compatibility | - |
| Standards/regulations | IEC 60664 |
| Mounting Type | DIN rail mounting |
| Mounting position | any |
| Contact Connection type | - |
| Output fuse | - |
| Degree of protection (Installation location) | โฅ IP54 |
Ask for the Pricing of Phoenix Combination of Relay Interface PLC-RSC- 24DC/1/CB1-6 part no: 1328357 at unbeatable prices. Detailed Specifications of PLC-RSC- 24DC/1/CB1-6, 1328357 feature Relay Module type and PLC-INTERFACE Product family a versatile solution for with integrated electronic circuit breaker applications. This relay module features a mechanical service life of -, ensuring durability and reliability. With a maximum power dissipation of < 1.6 W, it operates efficiently at a nominal input voltage of -, within an input voltage range of -. The module has a typical input current of - at UN, with a response time of - and a release time of -. It is equipped with a - for protection and includes - made from Screw connection Connection method. Now's the Time to Secure a Quote for your requirement of Phoenix Combination of Relay Interface. We're committed to offering more favorable pricing and more responsive support than other Traders.
