Phoenix PLC-BSC- 24UC/21-21 Relay Socket
The Phoenix PLC-BSC- 24UC/21-21 Relay Socket (Part No: 2967028 ) offers a Screw connection method, 0.14 mmΒ² ... 2.5 mmΒ² conductor cross section rigid, 0.14 mmΒ² ... 2.5 mmΒ² conductor cross section flexible, DIN rail mounting mounting type. Manufactured by Phoenix under the Phoenix Relay Socket category, this model belongs to the Phoenix PLC Series.
| Brand | Phoenix Contact |
| Product Type | Relay Socket |
| Model Number | PLC-BSC- 24UC/21-21 |
Phoenix PLC-BSC- 24UC/21-21 Relay Socket β Technical Specifications
| Specification | Value |
|---|---|
| Product type | Relay socket |
| Product family | PLC-INTERFACE |
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Screw thread | M3 |
| Conductor cross section rigid | 0.14 mmΒ² ... 2.5 mmΒ² |
| Conductor cross section flexible | 0.14 mmΒ² ... 2.5 mmΒ² |
| Width | 14 mm |
| Height | 80 mm |
| Color | gray (RAL 7042) |
| Ambient temperature (operation) | -40 Β°C ... 60 Β°C |
| Ambient temperature (storage/transport) | -40 Β°C ... 85 Β°C |
| Mounting type | DIN rail mounting |
| Mounting position | any |
| Application | Universal |
| Protective circuit | Bridge rectifier |
| Nominal input voltage UN | 24 V AC/DC |
| Conductor cross section AWG | 26 ... 14 |
| Tightening torque | 0.6 Nm ... 0.8 Nm |
| Status display | LED |
| Depth | 94 mm |
| Flammability rating according to UL 94 | V0 (Housing) |
| Enclosure Low | Required protection according to the Rules shall be provided upon installation on board |
| Low Voltage Directive | Conformance with Low Voltage Directive |
| Electromagnetic compatibility | Conformance with EMC directive |
| Compatible components | Miniature relay, REL-MR-24DC/21-21AU, REL-MR-24DC/21-21 |
| Insulation | - |
Ask for the Pricing of Phoenix Screw Connection Relay Socket PLC-BSC- 24UC/21-21 part no: 2967028 at unbeatable prices. Detailed Specifications of PLC-BSC- 24UC/21-21, 2967028 feature Product family PLC-INTERFACE, designed for versatile industrial applications. This sensor features a reliable Screw connection method, accommodating conductor cross sections of 0.14 mmΒ² ... 2.5 mmΒ², whether rigid or flexible 0.14 mmΒ² ... 2.5 mmΒ². The sensor has compact dimensions, with a width of 14 mm and a height of 80 mm, making it suitable for space-constrained installations. The housing is finished in gray (RAL 7042), ensuring a professional appearance. It operates efficiently within ambient temperatures ranging from -40 Β°C ... 60 Β°C, both during operation and storage. The sensor is designed for easy DIN rail mounting, allowing for flexible mounting positions in any orientation. Now's the Time to Secure a Quote for your requirement of Phoenix Screw Connection Relay Socket. We're committed to offering more favorable pricing and more responsive support than other Traders.
