Phoenix FL SWITCH 2316 Industrial Ethernet Switches
The Phoenix FL SWITCH 2316 Power Supply (Part No: 2702909 ) offers a Push-in spring connection method, 10/100/1000 Mbps transmission speed, 12 V DC ... 57 V DC supply voltage range, IP20 degree of protection. Manufactured by Phoenix under the Phoenix Industrial Ethernet Switches category, this model belongs to the Phoenix FL Series.
| Brand | Phoenix Contact |
| Product Type | Industrial Ethernet switches |
| Model Number | FL SWITCH 2316 |
Phoenix FL SWITCH 2316 Industrial Ethernet Switches
| Specification | Value |
|---|---|
| Width | 85 mm |
| Height | 130 mm |
| Depth | 119 mm |
| Housing material | Polycarbonate fiber reinforced |
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| Transmission speed | 10/100/1000 Mbps |
| Transmission length | 100 m (per segment) |
| Signal LEDs | Data receive, link status |
| No. of channels | 16 (RJ45 ports) |
| Product type | Switch |
| MTTF | 379.84 Years (SN 29500 standard, temperature 25°C, operating cycle 21%) |
| Article revision | 6 |
| Supply voltage (DC) | 24 V DC (redundant) |
| Supply voltage range | 12 V DC ... 57 V DC |
| Power supply connection | via COMBICON, max. conductor cross section 1.5 mm² |
| Max. current consumption | 1.8 A (US = Min, Tamb = Max, DOI = Max) |
| Typical current consumption | 455 mA (at US = 24 V DC and 25 °C ambient temperature) |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -40 °C ... 70 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 10 % ... 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % ... 95 % (non-condensing) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Noise emission | EN 61000-6-4 |
| Status display | LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (Link/Activity and Speed) |
| Shock (operation) | 30g (EN 60068-2-27) |
| Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz |
The Phoenix Contact FL SWITCH 2316 (Part No: 2702909) is a robust 16 port Ethernet Switch designed for high-performance industrial networks. It features sixteen RJ45 ports supporting 10/100/1000 Mbps transmission speed, allowing seamless communication between PLCs, HMIs, SCADA systems, and controllers. The phoenix contact 16 port ethernet switch operates with a 24 V DC redundant supply and accepts a wide input range of 12–57 V DC for continuous reliability. Its push-in spring connection and DIN rail mounting simplify panel integration and ensure maintenance-free installation. Constructed with polycarbonate fiber-reinforced housing and IP20 protection, the FL-SWITCH-2316-2702909 provides excellent durability under vibration, shock, and temperature extremes from -40°C to +70°C. It maintains low current consumption of 455 mA at 24 V DC while offering LED indicators for power, link, and speed diagnostics, which help engineers monitor network health efficiently. With a mean time to failure of 379.84 years, the phoenix contact 2702909 is a long-lasting solution trusted for industrial-grade Ethernet performance.
The Phoenix Contact FL SWITCH 2316 is widely used across automation lines, packaging systems, and process industries where high-speed and stable communication is vital. Engineers rely on this phoenix ethernet switch 16 port to connect PLCs, HMIs, and remote I/O modules within control cabinets. It supports a 100-meter transmission length per segment, enabling efficient cabling across large plant areas. Maintenance engineers appreciate its rugged design and easy push-in connections, which reduce downtime during replacements or upgrades. The 16 port ethernet switch phoenix ensures reliable data transfer under high humidity, shock, and temperature variations, making it ideal for continuous 24/7 production environments. Its EMC compliance and energy-efficient design further enhance performance in power-sensitive applications, aligning perfectly with modern smart factory needs.
For buyers and system integrators seeking dependable Ethernet solutions, the FL SWITCH 2316 (Part No: 2702909) by Phoenix Contact stands out as a proven industrial performer. This ethernet switch 16 port phoenix offers excellent scalability, advanced diagnostics, and robust construction that supports long operational life. Its fiber-reinforced housing and redundant 24 V DC design ensure uninterrupted communication even in power-variable environments. The fl switch tsn 2316 combines precision engineering with global compliance standards, providing superior reliability in industrial networking. For verified documentation, technical drawings, and installation guides, visit the official Phoenix Contact product page for the FL SWITCH 2316 (Part No: 2702909).
