Phoenix FL SWITCH 2214-2FX SM Industrial Ethernet Switches
The Phoenix FL SWITCH 2214-2FX SM Power Supply (Part No: 2702906 ) offers a Push-in spring connection method, 100 Mbps (full duplex) transmission speed, 12 V DC ... 57 V DC supply voltage range, IP20 degree of protection. Manufactured by Phoenix under the Phoenix Industrial Ethernet Switches category, this model belongs to the Phoenix FL Series.
| Brand | Phoenix Contact |
| Product Type | Industrial Ethernet switches |
| Model Number | FL SWITCH 2214-2FX SM |
Phoenix FL SWITCH 2214-2FX SM Industrial Ethernet Switches
| Specification | Value |
|---|---|
| Width | 85 mm |
| Height | 130 mm |
| Depth | 119 mm |
| Housing material | Polycarbonate fiber reinforced |
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| Transmission speed | 100 Mbps (full duplex) |
| Transmission length | 36000 m (fiberglass with F-G 9/125 0.36 dB/km) |
| Signal LEDs | Data receive, link status |
| No. of channels | 2 (SC single mode) |
| Product type | Switch |
| MTTF | 264.71 Years (SN 29500 standard, temperature 25°C, operating cycle 21%) |
| Article revision | 4 |
| Supply voltage (DC) | 24 V DC (redundant) |
| Supply voltage range | 12 V DC ... 57 V DC |
| Power supply connection | via COMBICON, max. conductor cross section 1.5 mm² |
| Max. current consumption | 1.8 A (US = Min, Tamb = Max, DOI = Max) |
| Typical current consumption | 375 mA (at US = 24 V DC and 25 °C ambient temperature) |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -40 °C ... 70 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 10 % ... 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % ... 95 % (non-condensing) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Noise emission | EN 61000-6-4 |
| Status display | LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (Link/Activity and Speed) |
| Shock (operation) | 30g (EN 60068-2-27) |
| Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz |
Call us for Phoenix 14 port Managed Switch FL SWITCH 2214-2FX SM part no: 2702906 at the best rates. Technical Attributes of FL SWITCH 2214-2FX SM, 2702906 are Polycarbonate fiber reinforced housing material, ensuring long-lasting performance in demanding environments. It supports easy installation with a standard DIN rail mounting making it ideal for streamlined setup in control panels. The connection method is via reliable Push-in spring connection, providing secure and stable connectivity. With a transmission speed of 100 Mbps (full duplex) it ensures fast and efficient data communication across networks. The relay supports a transmission length of up to 36000 m (fiberglass with F-G 9/125 0.36 dB/km) making it versatile for various industrial settings. It features 2 (SC single mode). Unlock Exclusive Pricing with a Quote for your requirement of Phoenix 14 port Managed Switch. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
