Phoenix FL SWITCH 1708 Industrial Ethernet Switches
The Phoenix FL SWITCH 1708 Power Supply (Part No: 1196228 ) offers a M12 connector (A-coded) method, 10/100/1000 Mbps transmission speed, 9 V DC ... 57 V DC supply voltage range, IP65 degree of protection. Manufactured by Phoenix under the Phoenix Industrial Ethernet Switches category, this model belongs to the Phoenix FL Series.
| Brand | Phoenix Contact |
| Product Type | Industrial Ethernet switches |
| Model Number | FL SWITCH 1708 |
Phoenix FL SWITCH 1708 Industrial Ethernet Switches
| Specification | Value |
|---|---|
| Width | 60 mm |
| Height | 226 mm |
| Depth | 46 mm |
| Housing material | Zinc die-cast |
| Mounting type | Wall mounting |
| Connection method | M12 connector (A-coded) |
| Transmission speed | 10/100/1000 Mbps |
| Transmission length | 100 m (per segment) |
| Signal LEDs | Data receive, link status |
| No. of channels | 8 (M12 ports) |
| Product type | Switch |
| MTTF | 56.6 Years (MIL-HDBK-217F standard, temperature 25°C, operating cycle 100%) |
| Article revision | 1 |
| Supply voltage (DC) | 24 V DC (redundant) |
| Supply voltage range | 9 V DC ... 57 V DC |
| Max. current consumption | 390 mA (9 V DC) |
| Typical current consumption | 142 mA |
| Degree of protection | IP65 |
| Ambient temperature (operation) | -40 °C ... 75 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 10 % ... 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % ... 95 % (non-condensing) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Noise emission | EN 61000-6-4 |
| Status display | LEDs: US1, US2 (power supply), 2 LEDs per Ethernet port (Link/Activity and Speed) |
| Shock (operation) | 30g (EN 60068-2-27) |
| Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz |
The Phoenix Contact FL SWITCH 1708, part number 1196228, is a robust Phoenix 8 M12 ports Unmanaged Switch designed for industrial Ethernet communication. It offers 8 M12 ports with 10/100/1000 Mbps speed, ensuring efficient data transmission across segments up to 100 meters. The device uses M12 A-coded connectors to guarantee vibration-resistant, secure connections in field-level applications.
Its zinc die-cast housing is built to withstand harsh industrial conditions, offering IP65 protection against dust and water ingress. Powered via a redundant 24 V DC supply (operating range 9–57 V DC), the unit consumes just 142 mA typically, delivering long-term energy efficiency. With a high MTTF of 56.6 years and full compliance with EMC Directive 2014/30/EU, it ensures reliable, uninterrupted operation. LED indicators for power and link status help in real-time diagnostics, while wall mounting enables secure installation in space-constrained areas.
Choose FL SWITCH 1708 for rugged networking where environmental reliability matters. Built by Phoenix Contact, this switch combines German engineering with practical usability. View more models on the Phoenix Contact product catalog or contact us to request a quote tailored to your industrial requirements.
