Phoenix TR-ES-OFF-CC-24/240-10H Time Relay
The Phoenix TR-ES-OFF-CC-24/240-10H Time Relay (Part No: 2907320 ) offers a 24 V DC ... 48 V DC -10 % ... +10 % input voltage range, 50 ms ... 10 h (6 time end ranges) setting range time, 5 A (fast-blow) output fuse, Screw connection method. Manufactured by Phoenix under the Phoenix Power Supply category, this model belongs to the Phoenix TR Series.
| Brand | Phoenix Contact |
| Product Type | Time Relays |
| Model Number | TR-ES-OFF-CC-24/240-10H |
Phoenix TR-ES-OFF-CC-24/240-10H Time Relay – Technical Specifications
| Specification | Value |
|---|---|
| Product type | Timer relay |
| Mechanical service life | approx. 1x 106 switching cycles |
| Service life electrical | approx. 1x 105 cycles |
| Nominal frequency | 48 Hz ... 63 Hz |
| Nominal power consumption | 8 VA (1 W, 230 V AC) |
| Test voltage relay winding/relay contact | 1.6 kV |
| Rated insulation voltage | 300 V |
| Input voltage range | 24 V DC ... 48 V DC -10 % ... +10 % |
| Temperature coefficient, typical | < 0.05 %/°C |
| Recovery time | > 100 ms |
| Setting range time | 50 ms ... 10 h (6 time end ranges) |
| Basic accuracy | < 1.5 % (of scale end value) |
| Setting accuracy | < 5 % (of scale end value) |
| Repeat accuracy | < 0.5 % ±5 ms |
| Maximum switching voltage | 250 V AC |
| Interrupting rating (ohmic load) max. | 1250 VA (5 A / 250 V AC) |
| Output fuse | 5 A (fast-blow) |
| Connection method | Screw connection |
| Stripping length | 7 mm |
| Conductor cross section rigid | 0.25 mm² ... 2.5 mm² |
| Status display | Green LED (POWER) |
| Degree of protection (Housing) | IP40 (Housing) |
| Ambient temperature (operation) | -25 °C ... 50 °C |
Give Us a Call for Phoenix Contact Time Delay Relay TR-ES-OFF-CC-24/240-10H part no: 2907320 at the lowest pricing. In-depth Technical Analysis of TR-ES-OFF-CC-24/240-10H, 2907320 feature Timer relay boasts an impressive mechanical service life of approximately approx. 1x 106 switching cycles ensuring long-term reliability. With a rated insulation voltage of 300 V it supports a wide input voltage range of 24 V DC ... 48 V DC -10 % ... +10 %. The relay features a quick recovery time of over > 100 ms and a versatile setting range time from 50 ms ... 10 h (6 time end ranges) different time ranges. For safety, it includes a 5 A (fast-blow) output fuse. The relay is connected via a secure Screw connection with a stripping length of 7 mm for easy installation. Elevate Your Project with a Quote for your requirement of Phoenix Contact Time Delay Relay. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
