Phoenix Contact RBO 5-T E - 3059553 - Bolt connection terminal block
Technical Specifications of Bolt connection terminal block RBO 5-T E 3059553
| Brand | Phoenix Contact |
| Product Type | Terminal Block |
| Product | RBO 5-T E |
Phoenix Contact Bolt connection terminal block RBO 5-T E, 3059553 Technical Specifications
| Specification | Value |
|---|---|
| Product type | Bolt connection terminal block |
| DIN rail/fixing support | NS 35/15 |
| Number of connections | 2 |
| Number of rows | 1 |
| Potentials | 1 |
| Overvoltage category | III |
| Degree of pollution | 3 |
| Rated surge voltage | 8 kV |
| Number of connections per level | 2 |
| Nominal cross section | 6 mmΓΒ² |
| Stripping length | The stripping length depends on the specification provided by the cable lug manufacturer. |
| Connection in acc. with standard | IEC 6094771 |
| Nominal current | 41 A |
| Maximum load current | 50 A (with 10 mmΓΒ² conductor cross section) |
| Nominal voltage | 800 V |
| Width | 13 mm |
| End cover width | 2.2 mm |
| Height | 80.75 mm |
| Depth on NS 35/7,5 | 49.8 mm |
| Depth on NS 35/15 | 57.3 mm |
| Color | dark gray |
| Flammability rating according to UL 94 | V0 |
| Insulating material group | I |
| Insulating material | PA |
| Static insulating material application in cold | 60 ΓΒ°C |
| Relative insulation material temperature index (Elec., UL 746 B) | 130 ΓΒ°C |
| Fire protection for rail vehicles (DIN EN 45545-2) R22 | HL 1 HL 3 |
| Fire protection for rail vehicles (DIN EN 45545-2) R23 | HL 1 HL 3 |
| Fire protection for rail vehicles (DIN EN 45545-2) R24 | HL 1 HL 3 |
| Fire protection for rail vehicles (DIN EN 45545-2) R26 | HL 1 HL 3 |
| Surface flammability NFPA 130 (ASTM E 162) | passed |
| Specific optical density of smoke NFPA 130 (ASTM E 662) | passed |
| Smoke gas toxicity NFPA 130 (SMP 800C) | passed |
| Test voltage setpoint | 1.89 kV |
| Result | Test passed |
| Requirement temperature-rise test | Increase in temperature Γ’ΒΒ€ 45 K |
| Open side panel | Yes |
| DIN rail/fixing support | NS 32/NS 35 |
| Test force setpoint | 5 N |
| Time of exposure | 30 s |
| Ambient temperature (operation) | 60 ΓΒ°C ... 110 ΓΒ°C (Operating temperature range incl. selfheating; for max. shortterm operating temperature, see RTI Elec.) |
| Ambient temperature (storage/transport) | 25 ΓΒ°C ... 60 ΓΒ°C (for a short time, not exceeding 24 h, 60 ΓΒ°C to +70 ΓΒ°C) |
| Ambient temperature (assembly) | 5 ΓΒ°C ... 70 ΓΒ°C |
| Ambient temperature (actuation) | 5 ΓΒ°C ... 70 ΓΒ°C |
| Permissible humidity (operation) | 20 % ... 90 % |
| Permissible humidity (storage/transport) | 30 % ... 70 % |
| Mounting type | NS 35/7,5 |
| Screw thread | M5 |
| Tightening torque | 2 ... 2.2 Nm |
| Specification | DIN EN 50155 (VDE 0115200):201805 |
| Spectrum | Long life test category 2, bogiemounted |
| Frequency | f1 = 5 Hz to f2 = 250 Hz |
| ASD level | 6.12 (m/sΓΒ²)ΓΒ²/Hz |
| Acceleration | 30g |
| Test duration per axis | 5 h |
| Test directions | X, Y and Zaxis (pos. and neg.) |
| Pulse shape | Halfsine |
| Shock duration | 18 ms |
| Number of shocks per direction | 3 |
| Note | Checked at 1100 V |
| Pitch | 13 mm |
| Tightening torque disconnect slide | 1.2 ... 1.4 Nm |
| Cross section | 1 mmΓΒ² ... 6 mmΓΒ² |
| Cross section range AWG | 20 ... 10 (converted acc. to IEC) |
| Hole diameter | 5.3 mm |
| Bolt diameter | 5 mm |
| Identification color of ring cable lugs : red | 1 mmΓΒ² |
| Identification color of ring cable lugs : blue | 2.5 mmΓΒ² |
| Identification color of ring cable lugs : yellow | 6 mmΓΒ² |
| Depth | 48.6 mm |
| Short-time withstand current 10 mmΓΒ² | 1.2 kA |
