Phoenix Contact PSR-PC52-1NO-1NC-24DC-SC - 1017062 - Coupling relay
Technical Specifications of Coupling relay PSR-PC52-1NO-1NC-24DC-SC 1017062
| Brand | Phoenix Contact |
| Product Type | Safe Coupling Relays |
| Product | PSR-PC52-1NO-1NC-24DC-SC |
Phoenix Contact Coupling relay PSR-PC52-1NO-1NC-24DC-SC, 1017062 Technical Specifications
| Specification | Value |
|---|---|
| Note on application | Only for industrial use |
| Product type | Coupling relay |
| Product family | PSRmini |
| Application | Safe switch on |
| Output fuse | Class I, Div. 2, Groups A, B, C, D, T4 |
| Control | 1 and 2 channel |
| Mechanical service life | approx. 5x 107 cycles |
| Relay type | Electromechanical relay |
| Overvoltage category | III |
| Degree of pollution | 2 |
| Recovery time | 1 s (when controlled via A1-A2) |
| Maximum power dissipation for nominal condition | 3.8 W (ati UB = 26.4 V DC, UBD = 26.4 V DC, IL = 3 A) |
| Nominal operating mode | 100% operating factor |
| Rated insulation voltage | 250 V AC |
| Rated surge voltage/insulation | Basic insulation 4 kV between all current paths and housing |
| Rated control circuit supply voltage US | 24 V DC -15 % / +10 % |
| Power consumption at US | typ. 2 W (at US/UD; On state) |
| Rated control supply current IS | typ. 75 mA |
| Typ. starting time with Us | typ. 100 ms (when controlled via A1-A2) |
| Typical release time | typ. 30 ms (when controlled via A1-A2) |
| Operating voltage display | 1 x LED (yellow) |
| Contact switching type | 1 signaling current path |
| Contact material | AgNi, gold-flashed, Ag alloy |
| Limiting continuous current | 3 A (Observe derating, load type, and on-load voltage) |
| Sq. Total current | 9 A2 (observe derating) |
| Switching capacity | min. 1 W |
| pluggable | yes |
| Connection method | Screw connection |
| Conductor cross section rigid | 0.2 mmยฒ ... 2.5 mmยฒ |
| Conductor cross section flexible | 0.2 mmยฒ ... 2.5 mmยฒ |
| Conductor cross-section AWG | 24 ... 12 |
| Stripping length | 7 mm |
| Screw thread | M3 |
| Width | 17.5 mm |
| Height | 112.2 mm |
| Depth | 114.5 mm |
| Color (Housing) | yellow (RAL 1018) |
| Housing material | Frianyl A63 RV0 |
| Safety Integrity Level (SIL) | 3 |
| Degree of protection | IP20 |
| Min. degree of protection of inst. location | IP54 |
| Ambient temperature (operation) | -25 ยฐC ... 60 ยฐC (observe derating) |
| Ambient temperature (storage/transport) | -40 ยฐC ... 65 ยฐC |
| Maximum altitude | โค 2000 m (Above sea level) |
| Max. permissible humidity (storage/transport) | 75 % (on average, 85% infrequently, non-condensing) |
| Max. permissible relative humidity (operation) | 75 % (on average, 85% infrequently, non-condensing) |
| Shock | 15g, 11 ms |
| Vibration (operation) | 10 Hz ... 150 Hz, 2g |
| Certificate | 2022122304115696 |
| Mounting type | DIN rail mounting |
| Mounting position | vertical or horizontal |
| Inrush current | โค 800 mA (ฮt ยฃ 100 ms) |
| Filter time | 2 ms (at A1-A2 in the event of voltage dips at Us) |
| Protective circuit | Surge protection; 36 V suppressor diode |
| Designation | 24V/0V |
| Power consumption at UD | typ. 0.9 W (at UD; Off state) |
| Status display | 1 x LED (green) |
| Output description | non-safety-related N/C contact |
| Number of outputs | 1 (without delay, floating) |
| Switching frequency | max. 0.5 Hz |
| Identification | Ex ec nC IIC T4 Gc |
| Assembly note | See derating curve |
| CCCex note | Use in potentially explosive areas is not permitted in China. |
| Diagnostic supply voltage UD | 24 V DC -20 % / +25 % |
| Input current at UD | 35 mA (at UD = 24 V) |
| Inrush current at UD | 1.5 A (ฮt < 10 ยตs) |
| Switching voltage | min. 16 V AC/DC |
| Short-circuit protection | no |
| Error indication | 1 x LED (red) |
| Number of inputs | 3 |
| Current consumption | typ. 20 mA (Input TP1) |
| Switching current | max. 100 mA |
| Air pressure (operation) | 79 kPa ... 106 kPa |
| Air pressure (storage/transport) | 79 kPa ... 106 kPa |
