Phoenix Contact PSR-MC72-2NO-1DO-24DC-SP - 2702097 - Safety relays
Technical Specifications of Safety relays PSR-MC72-2NO-1DO-24DC-SP 2702097
| Brand | Phoenix Contact |
| Product Type | Safety Relays |
| Product | PSR-MC72-2NO-1DO-24DC-SP |
Phoenix Contact Safety relays PSR-MC72-2NO-1DO-24DC-SP, 2702097 Technical Specifications
| Specification | Value |
|---|---|
| Note on application | Only for industrial use |
| Product type | Safety relays |
| Product family | PSRmini |
| Application | Emergency stop |
| Control | 1 and 2 channel |
| Mechanical service life | 10x 106 cycles |
| Relay type | Electromechanical relay with force-guided contacts in accordance with IEC/EN 61810-3 |
| Overvoltage category | III |
| Degree of pollution | 2 |
| Typical response time | < 35 ms (automatic start) |
| Typical release time | < 25 ms (when controlled via S12 (only for undelayed contact 13/14)) |
| Restart time | < 1 s (Boot time) |
| Maximum power dissipation for nominal condition | 5.78 W (at US = 30 V, IL² = 72 A²) |
| Nominal operating mode | 100% operating factor |
| Rated insulation voltage | 250 V AC |
| Rated surge voltage/insulation | See section “Insulation coordination” |
| Description of the input | non-safety-related |
| Number of inputs | 1 |
| Inrush current | min. 3 mA |
| Filter time | max. 3 ms (Test pulse width of low test pulses) |
| Max. permissible overall conductor resistance | 150 Ω |
| Protective circuit | Surge protection; Suppressor diode |
| Current consumption | < 3.2 mA (typ. with US) |
| Output description | PNP |
| Number of outputs | 1 |
| Contact switching type | 2 enabling current paths |
| Contact material | AgSnO2 |
| Switching voltage | min. 12 V AC/DC |
| Switching capacity | min. 60 mW |
| Limiting continuous current | 6 A (observe derating) |
| Sq. Total current | 72 A2 (observe derating) |
| Switching frequency | 0.1 Hz |
| Output fuse | 6 A gL/gG (N/O contact) |
| pluggable | yes |
| Connection method | Push-in connection |
| Conductor cross section rigid | 0.2 mm² ... 1.5 mm² |
| Conductor cross section flexible | 0.2 mm² ... 1.5 mm² |
| Conductor cross-section AWG | 24 ... 16 |
| Stripping length | 8 mm |
| Status display | 5 x bi-color LED |
| Width | 12.5 mm |
| Height | 116.6 mm |
| Depth | 114.5 mm |
| Color (Housing) | yellow (RAL 1018) |
| Housing material | PA |
| Category | 4 |
| Performance level (PL) | e |
| Safety Integrity Level (SIL) | 3 |
| Degree of protection | IP20 |
| Min. degree of protection of inst. location | IP54 |
| Ambient temperature (operation) | -35 °C ... 60 °C (observe derating) |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Maximum altitude | ≤ 2000 m (Above sea level) |
| Max. permissible humidity (storage/transport) | 75 % (on average, 85% infrequently, non-condensing) |
| Max. permissible relative humidity (operation) | 75 % (on average, 85% infrequently, non-condensing) |
| Shock | 15g |
| Vibration (operation) | 10 Hz ... 150 Hz, amplitude 0.15 mm, 2g |
| Identification | CE-compliant |
| Mounting type | DIN rail mounting |
| Mounting position | vertical or horizontal |
| Rated control circuit supply voltage US | 24 V DC -20 % / +25 % |
| Rated control supply current IS | typ. 60 mA |
| Power consumption at US | typ. 1.44 W |
| Input voltage range "0" signal | 0 V DC ... 5 V DC |
| Input current range "0" signal | 0 mA ... 2 mA |
| Concurrence | ∞ |
| Assembly note | See derating curve |
| Voltage at input/start and feedback circuit | 24 V DC -20 % / +25 % |
| Maximum inrush current | 500 mA (Δt = 1 ms at Us) |
| Designation | A1/A2 |
| Delay time range | 0.2 s ... 60 s ±5 % (can be set for 27/28) |
| Conductor cross section, flexible, with ferrule, with plastic sleeve | 0.25 mm² ... 1.5 mm² (only together with CRIMPFOX 6) |
| Conductor cross section flexible, with ferrule without plastic sleeve | 0.25 mm² ... 1.5 mm² (only together with CRIMPFOX 6) |
| Voltage | approx. 23 V DC (US - 1 V) |
| Current | max. 100 mA |
| Limit frequency | min. 0 Hz |
| Short-circuit protection | Yes |
| EMC note | EMC: class A product, see manufacturer's declaration in the download area |
