Phoenix Contact PSR-MC45-3NO-1DO-24DC-SP - 1082029 - Safety relays
Technical Specifications of Safety relays PSR-MC45-3NO-1DO-24DC-SP 1082029
| Brand | Phoenix Contact |
| Product Type | Safety Relays |
| Product | PSR-MC45-3NO-1DO-24DC-SP |
Phoenix Contact Safety relays PSR-MC45-3NO-1DO-24DC-SP, 1082029 Technical Specifications
| Specification | Value |
|---|---|
| Note on application | Only for industrial use |
| Product type | Safety relays |
| Product family | PSRmini |
| Application | Emergency stop |
| Control | 1 and 2 channel |
| Mechanical service life | 10x 106 cycles |
| Relay type | Electromechanical relay with force-guided contacts in accordance with IEC/EN 61810-3 |
| Overvoltage category | II |
| Degree of pollution | 2 |
| Typical response time | < 100 ms (automatic start) |
| Typ. starting time with Us | < 100 ms (when controlled via A1) |
| Typical release time | < 20 ms (on demand via the sensor circuit) |
| Restart time | < 1 s (Boot time) |
| Recovery time | 500 ms (following demand of the safety function) |
| Maximum power dissipation for nominal condition | 17.21 W (at UB = 30 V , ILΒ² = 72 AΒ²) |
| Nominal operating mode | 100% operating factor |
| Rated insulation voltage | 250 V AC |
| Rated surge voltage/insulation | Basic insulation 4 kV between all current paths |
| Description of the input | non-safety-related |
| Number of inputs | 2 |
| Input voltage range "1" signal | 19.2 V DC ... 30 V DC |
| Inrush current | min. 10 mA AC/DC |
| Filter time | max. 3 ms (Test pulse width of low test pulses) |
| Max. permissible overall conductor resistance | 150 Ξ© |
| Protective circuit | 33 V suppressor diode |
| Current consumption | 2.5 mA (typ. with US at S34) |
| Output description | PNP |
| Number of outputs | 1 |
| Contact switching type | 3 enabling current paths |
| Contact material | AgSnO2 |
| Switching voltage | min. 5 V AC/DC |
| Switching capacity | min. 50 mW |
| Limiting continuous current | 6 A |
| Sq. Total current | 72 A2 (observe derating) |
| Switching frequency | 0.5 Hz (ohmic) |
| Output fuse | 6 A gL/gG |
| pluggable | yes |
| Connection method | Push-in connection |
| Conductor cross section rigid | 0.2 mmΒ² ... 1.5 mmΒ² |
| Conductor cross section flexible | 0.2 mmΒ² ... 1.5 mmΒ² |
| Conductor cross-section AWG | 24 ... 16 |
| Stripping length | 8 mm |
| Status display | 2 x LED (green) |
| Operating voltage display | 1 x LED (green) |
| Width | 22.5 mm |
| Height | 117.4 mm |
| Depth | 114.5 mm |
| Color (Housing) | yellow (RAL 1018) |
| Housing material | PA |
| Category | 4 |
| Performance level (PL) | e (5 A DC13; 8760 switching cycles/year or 5 A AC15; 2190 switching cycles/year) |
| Safety Integrity Level (SIL) | 3 |
| Degree of protection | IP20 |
| Min. degree of protection of inst. location | IP54 |
| Ambient temperature (operation) | -40 Β°C ... 60 Β°C (observe derating) |
| Ambient temperature (storage/transport) | -40 Β°C ... 85 Β°C |
| Maximum altitude | β€ 2000 m (Above sea level) |
| Max. permissible humidity (storage/transport) | 75 % (on average, 85% infrequently, non-condensing) |
| Max. permissible relative humidity (operation) | 75 % (on average, 85% infrequently, non-condensing) |
| Shock | 15g for Ξt = 11 ms (continuous shock: 10g for Ξt = 16 ms) |
| Vibration (operation) | 10 Hz ... 150 Hz, 2g |
| Identification | CE-compliant |
| Mounting type | DIN rail mounting |
| Mounting position | vertical or horizontal |
| Rated control circuit supply voltage US | 24 V DC -20 % / +25 % (provide external protection) |
| Rated control supply current IS | typ. 75 mA |
| Power consumption at US | typ. 1.8 W |
| Input voltage range "0" signal | 0 V ... 5 V (S10, S12) |
| Input current range "0" signal | 0 mA ... 2 mA (S10, S12) |
| Concurrence | β |
| Assembly note | See derating curve |
| Maximum inrush current | 1 A (Ξt = 5 ms at Us) |
| Designation | A1/A2 |
| Conductor cross section, flexible, with ferrule, with plastic sleeve | 0.25 mmΒ² ... 1.5 mmΒ² (only together with CRIMPFOX 6) |
| Conductor cross section flexible, with ferrule without plastic sleeve | 0.25 mmΒ² ... 1.5 mmΒ² (only together with CRIMPFOX 6) |
| Voltage | approx. 23 V DC (Us - 1 V) |
| Current | max. 100 mA |
| Short-circuit protection | Yes |
