Phoenix Contact PSR-ESS-M0-H200-2000-C - 1221740 - Emergency stop switch
Technical Specifications of Emergency stop switch PSR-ESS-M0-H200-2000-C 1221740
| Brand | Phoenix Contact |
| Product Type | Emergency Stop Switch |
| Product | PSR-ESS-M0-H200-2000-C |
Phoenix Contact Emergency stop switch PSR-ESS-M0-H200-2000-C, 1221740 Technical Specifications
| Specification | Value |
|---|---|
| Note on application | Only for industrial use |
| Product type | Emergency stop switch |
| Overvoltage category | III |
| Pollution degree | 3 |
| Rated surge voltage | 2.5 kV |
| Voltage | max. (see load limit current) |
| Current | max. (see load limit current) |
| Contact switching type | 2 forceguided N/C contacts |
| Contact material | AgNi |
| Electrical service life | 50,000 switching cycles |
| Mechanical service life | 50,000 switching cycles |
| Bouncing time | < 10 ms |
| Standard | IEC/EN 6094751 |
| Connection method | Spade connection |
| Depth | 44.1 mm |
| Flammability rating according to UL 94 | V2 (Actuator) |
| Housing material | PA |
| Degree of protection | IP65/IP67 (with professional installation in the appropriate installation space) |
| Ambient temperature (operation) | 25 ΓΒ°C ... 70 ΓΒ°C |
| Ambient temperature (storage/transport) | 40 ΓΒ°C ... 80 ΓΒ°C |
| Maximum altitude | max. 2000 m (Above sea level) |
| Shock | 15g / 11 ms, in accordance with IEC 60068227 |
| Vibration (operation) | 10 Hz ... 500 Hz, 0.35 mm amplitude, 5g, in accordance with IEC 6006826 |
| Mounting type | Panel mount |
| Mounting position | any |
| Diameter | 28 mm |
| Color (Mushroom head button) | red (RAL 3001) |
| Color (Front frame) | yellow (RAL 1018) |
| Assembly note | Mounting nut torque: 1.3 Nm Γ’ΒΒ¦ 1.9 Nm |
