Phoenix PLC-V8C/SC-24DC/SAM2 Logic Modules
The Phoenix PLC-V8C/SC-24DC/SAM2 Logic Modules (Part No: 2907445 ) offers a PLC logicproduct family, 100% operating factor operating mode, S-PORT (socket) connection method, 0.14 mm² ... 1.5 mm² conductor cross section rigid. Manufactured by Phoenix under the Phoenix Logic Modules category, this model belongs to the Phoenix PLC Series.
| Brand | Phoenix Contact |
| Product Type | Logic Modules |
| Model Number | PLC-V8C/SC-24DC/SAM2 |
Phoenix PLC-V8C/SC-24DC/SAM2 Logic Modules – Technical Specifications
| Specification | Value |
|---|---|
| Product type | Base unit |
| Product family | PLC logic |
| Operating mode | 100% operating factor |
| Insulation | Basic insulation |
| Overvoltage category | III |
| Rated insulation voltage | 50 V |
| Rated surge voltage | 0.8 kV |
| Supply voltage | 24 V DC |
| Supply voltage range | 19.2 V DC ... 26.4 V DC |
| Maximum input current at UN | 160 mA |
| Number of inputs | ≤ 8 |
| Input voltage | 19 V DC |
| Input current "0" signal | < 1 mA |
| Input current "1" signal | 2.5 mA |
| Input resistance | < 100 mΩ |
| Number of outputs | ≤ 8 |
| Nominal output voltage | 24 V DC |
| Nominal current | 9 mA |
| Connection method | S-PORT (socket) |
| Conductor cross section rigid | 0.14 mm² ... 1.5 mm² |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -20 °C ... 50 °C |
Get A Quote for Phoenix Contact 24V Relay PLC-V8C/SC-24DC/SAM2 part no: 2907445 at the best price. Here are the brief Technical Specifications of PLC-V8C/SC-24DC/SAM2, 2907445 are Base unit Product type, delivering reliable performance for your automation needs. This product belongs to the PLC logic family, ensuring 100% operating factor with Basic insulation for enhanced safety. The connection method is through an S-PORT (socket) supporting a conductor cross-section of 0.14 mm² ... 1.5 mm² for rigid conductors. The unit boasts an IP20 degree of protection, making it suitable for various industrial environments. It operates efficiently within an ambient temperature range of -20 °C ... 50 °C. It's Time to get a Quote for your requirement of Phoenix Contact 24V Relay. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
