Phoenix PLC-V8C/PT-24DC/EM Logic Modules
The Phoenix PLC-V8C/PT-24DC/EM Logic Modules (Part No: 2905137 ) offers a PLC logicproduct family, 100% operating factor operating mode, Insulation displacement connection connection method, 0.14 mm² ... 1.5 mm² conductor cross section rigid. Manufactured by Phoenix under the Phoenix Logic Modules category, this model belongs to the Phoenix PLC Series.
| Brand | Phoenix Contact |
| Product Type | Logic Modules |
| Model Number | PLC-V8C/PT-24DC/EM |
Phoenix PLC-V8C/PT-24DC/EM Logic Modules – Technical Specifications
| Specification | Value |
|---|---|
| Product type | Extension module |
| Product family | PLC logic |
| Operating mode | 100% operating factor |
| Insulation | Basic insulation |
| Overvoltage category | III |
| Rated insulation voltage | 50 V |
| Rated surge voltage | 0.8 kV |
| Supply voltage | 24 V DC |
| Supply voltage range | 19.2 V DC ... 26.4 V DC |
| Maximum input current at UN | 65 mA |
| Number of inputs | ≤ 8 |
| Input voltage | 19 V DC |
| Input current "0" signal | < 1 mA |
| Input current "1" signal | typ. 2.5 mA |
| Input resistance | < 100 mΩ |
| Number of outputs | ≤ 8 |
| Nominal output voltage | 24 V DC |
| Nominal current | 9 mA |
| Connection method | Insulation displacement connection |
| Conductor cross section rigid | 0.14 mm² ... 1.5 mm² |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -20 °C ... 50 °C |
| EMC note | EMC: class A product, see manufacturer's declaration in the download area |
Talk to Our Engineer for Phoenix Contact Extension Module PLC-V8C/PT-24DC/EM part no: 2905137 with exclusive offers. Core System Specifications of PLC-V8C/PT-24DC/EM, 2905137 are Extension module Product type, delivering reliable performance for your automation needs. This product belongs to the PLC logic family, ensuring 100% operating factor with Basic insulation for enhanced safety. The connection method is through an Insulation displacement connection supporting a conductor cross-section of 0.14 mm² ... 1.5 mm² for rigid conductors. The unit boasts an IP20 degree of protection, making it suitable for various industrial environments. It operates efficiently within an ambient temperature range of -20 °C ... 50 °C. Don't Miss Out on a Quote for your requirement of Phoenix Contact Extension Module. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
