Phoenix MACX-TR-1T-MUL Time Relay
The Phoenix MACX-TR-1T-MUL Time Relay (Part No: 1096429 ) offers a 24 V AC/DC ... 240 V AC/DC (-15 % ... +10 %) input voltage range, 10 ms ... 59999 min. (10 ms ... 999 h 59 min.) setting range time, 8 A (fast-blow) output fuse, Screw connection method. Manufactured by Phoenix under the Phoenix Power Supply category, this model belongs to the Phoenix TR Series.
| Brand | Phoenix Contact |
| Product Type | Time Relays |
| Model Number | MACX-TR-1T-MUL |
Phoenix MACX-TR-1T-MUL Time Relay β Technical Specifications
| Specification | Value |
|---|---|
| Product type | Timer relay |
| Mechanical service life | Approx. 3x 107 cycles |
| Service life electrical | approx. 1x 105 cycles, resistive load 2000 V A |
| Nominal frequency | 48 Hz ... 63 Hz |
| Nominal power consumption | 2.5 VA (0.8 W) |
| Rated insulation voltage | 300 V AC |
| Input voltage range | 24 V AC/DC ... 240 V AC/DC (-15 % ... +10 %) |
| Temperature coefficient, typical | β€ 0.01 %/Β°C |
| Recovery time | 100 ms |
| Setting range time | 10 ms ... 59999 min. (10 ms ... 999 h 59 min.) |
| Setting accuracy | β€ 0.5 % (οΌ1 s) |
| Repeat accuracy | β€ 0.05 % (οΌ1 s) |
| Maximum switching voltage | 400 V AC |
| Interrupting rating (ohmic load) max. | 2000 VA (8 A / 250 V AC) |
| Output fuse | 8 A (fast-blow) |
| Connection method | Screw connection |
| Stripping length | 10 mm |
| Conductor cross section rigid | 0.2 mmΒ² ... 2.5 mmΒ² |
| Ambient temperature (operation) | -25 Β°C ... 60 Β°C |
The Phoenix MACX-TR-1T-MUL Time Relay (Part No: 1096429) combines durability with advanced timing flexibility, making it ideal for critical timing operations in control systems. Its mechanical endurance reaches approximately 3Γ10β· cycles, while the electrical service life supports up to 1Γ10β΅ cycles at 2000 VA resistive load, ensuring consistent operation in harsh industrial conditions. Operating across a wide input voltage range from 24 V AC/DC to 240 V AC/DC (Β±15%), this time relay adapts seamlessly to various power environments. It offers a low power consumption of 2.5 VA (0.8 W) and ensures electrical integrity with a rated insulation voltage of 300 V AC and a maximum switching voltage of 400 V AC. With high accuracy timing (β€ 0.5% setting accuracy and β€ 0.05% repeat accuracy), and a wide setting range from 10 ms to 59999 minutes (up to 999 hours 59 minutes), it supports ultra-precise timing in complex systems. A recovery time of just 100 ms ensures minimal delay between operations. Installation is straightforward via screw terminals with 10 mm stripping length, supporting 0.2β2.5 mmΒ² rigid conductor cross sections, backed by robust in-built protection through an 8 A fast-blow fuse.
This Phoenix Contact Time Relay is widely used in advanced automation panels, motor control centers, and sequential switching applications across manufacturing, process plants, and utility infrastructure. It excels in situations where timing needs varyβsuch as delay-on, interval, and pulse controlβgiving maintenance engineers precise control over actuation and shutdown processes. Whether youβre upgrading an existing control loop or building a new PLC-integrated panel, the MACX-TR-1T-MUL supports a broad spectrum of automation strategies. Junior and senior engineers alike will find it easy to configure due to its intuitive time range settings and reliable performance in both low and high voltage environments. This makes it a reliable teaching tool in technical institutions and a dependable solution in production lines, HVAC control, lighting systems, and more.
For complete technical documentation and certifications, visit the official product page: Phoenix MACX-TR-1T-MUL Product Page.
