Phoenix ETD-BL-2T-I-230-PT Time Relay
The Phoenix ETD-BL-2T-I-230-PT Time Relay (Part No: 2907714 ) offers a 24 V AC/DC ... 240 V AC/DC -10 % ... +15 % input voltage range, 50 ms ... 100 h (7 time end ranges) setting range time, 5 A (fast-blow) output fuse, Push-in connection method. Manufactured by Phoenix under the Phoenix Power Supply category, this model belongs to the Phoenix TR Series.
| Brand | Phoenix Contact |
| Product Type | Time Relays |
| Model Number | ETD-BL-2T-I-230-PT |
Phoenix ETD-BL-2T-I-230-PT Time Relay – Technical Specifications
| Specification | Value |
|---|---|
| Product type | Timer relay |
| Mechanical service life | approx. 2x 107 cycles |
| Service life electrical | approx. 2x 105 cycles at ohmic load, 1000 VA |
| Nominal frequency | 48 Hz ... 63 Hz |
| Nominal power consumption | 2.5 VA (1 W) |
| Test voltage relay winding/relay contact | 4 kV |
| Rated insulation voltage | 300 V |
| Input voltage range | 24 V AC/DC ... 240 V AC/DC -10 % ... +15 % |
| Temperature coefficient, typical | ≤ 0.01 %/K |
| Recovery time | 500 ms |
| Setting range time | 50 ms ... 100 h (7 time end ranges) |
| Basic accuracy | ± 1 % (of scale end value) |
| Setting accuracy | ≤ 5 % (of scale end value) |
| Repeat accuracy | ≤ 0.5 % ±5 ms |
| Maximum switching voltage | 250 V AC (in acc. with IEC 60664-1) |
| Interrupting rating (ohmic load) max. | 750 VA (3 A/250 V AC, module aligned, ≤ 5 mm spacing) |
| Output fuse | 5 A (fast-blow) |
| Connection method | Push-in connection |
| Stripping length | 8 mm |
| Conductor cross section rigid | 0.14 mm² ... 2.5 mm² |
| Status display | Green LED (POWER) |
| Degree of protection (Housing) | IP40 (Housing) |
| Ambient temperature (operation) | -25 °C ... 55 °C |
Talk to Our Engineer for Phoenix Compact Impulse Encoder Relay ETD-BL-2T-I-230-PT part no: 2907714 with exclusive offers. Core System Specifications of ETD-BL-2T-I-230-PT, 2907714 are Timer relay boasts an impressive mechanical service life of approximately approx. 2x 107 cycles ensuring long-term reliability. With a rated insulation voltage of 300 V it supports a wide input voltage range of 24 V AC/DC ... 240 V AC/DC -10 % ... +15 %. The relay features a quick recovery time of over 500 ms and a versatile setting range time from 50 ms ... 100 h (7 time end ranges) different time ranges. For safety, it includes a 5 A (fast-blow) output fuse. The relay is connected via a secure Push-in connection with a stripping length of 8 mm for easy installation. Don't Miss Out on a Quote for your requirement of Phoenix Compact Impulse Encoder Relay. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
