Phoenix ETD-BL-1T-230 Compact Multi-functional Timer Relay
The ETD-BL-1T-230 is a Phoenix Compact Multi-functional Timer Relay 2905813 with 24–240 V AC/DC input and 50 ms–1 h timing range. Manufactured by Phoenix Contact, this Phoenix Time Relay supports 24 V AC/DC to 240 V AC/DC input range, provides 50 ms–1 h setting range, allows 250 V AC maximum switching voltage, and delivers 1250 VA (5 A / 250 V AC) interrupting rating. It belongs to the Relay Series for industrial automation applications, with 4 VA nominal power consumption and screw connection terminals.
| Brand | Phoenix Contact |
| Product Type | Time Relays |
| Model Number | ETD-BL-1T-230 |
Phoenix ETD-BL-1T-230 Compact Multi-functional Timer Relay - Technical Specifications
| Specification | Value |
|---|---|
| Product type | Timer relay |
| Mechanical service life | 15x 106 cycles |
| Service life electrical | 1x 105 cycles |
| Nominal frequency | 48 Hz ... 63 Hz |
| Nominal power consumption | 4 VA |
| Test voltage relay winding/relay contact | 4 kV |
| Input voltage range | 24 V AC/DC ... 240 V AC/DC -15 % ... +10 % |
| Temperature coefficient, typical | ≤ 0.01 %/K |
| Recovery time | 100 ms |
| Setting range time | 50 ms ... 1 h (5 time end ranges) |
| Basic accuracy | ± 1 % (of scale end value) |
| Setting accuracy | ≤ 5 % (of scale end value) |
| Repeat accuracy | ≤ 0.5 % ±5 ms |
| Maximum switching voltage | 250 V AC (in acc. with IEC 60664-1) |
| Interrupting rating (ohmic load) max. | 1250 VA (5 A / 250 V AC) |
| Output fuse | 5 A (fast-blow) |
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Conductor cross section rigid | 0.5 mm² ... 2.5 mm² |
| Status display | Green LED (POWER) |
| Degree of protection (Housing) | IP40 (Housing) |
| Ambient temperature (operation) | -25 °C ... 55 °C |
The ETD-BL-1T-230 Phoenix Compact Multi-functional Timer Relay 2905813 is designed for timing control in industrial automation systems. It operates within a 24 V AC/DC to 240 V AC/DC input range and offers a 50 ms–1 h setting range across five selectable ranges. The relay supports 250 V AC maximum switching voltage with 1250 VA (5 A / 250 V AC) interrupting capacity. As part of the Relay Series, the ETD-BL-1T-230 integrates into control panels used across India.
In conveyors, packaging machinery, assembly systems, and process automation panels, the ETD-BL-1T-230 Phoenix Compact Multi-functional Timer Relay 2905813 enables delay-on, delay-off, and interval timing functions. With defined repeat accuracy and 100 ms recovery time, it maintains stable switching behavior under resistive loads. The screw connection method ensures secure installation within DIN rail-based cabinets.
The ETD-BL-1T-230 from Phoenix Contact provides specified mechanical and electrical service life ratings suited for routine industrial duty. Operating at nominal frequency 48 Hz to 63 Hz with 4 VA power consumption, it fits standard control architectures. As a Phoenix Compact Multi-functional Timer Relay 2905813 within the Relay Series, the ETD-BL-1T-230 supports structured timing control requirements in automation systems.
