Phoenix Contact CABLE-25/8/250/PSR-M/001/R - 1574602 - Adapter cable
Technical Specifications of Adapter cable CABLE-25/8/250/PSR-M/001/R 1574602
| Brand | Phoenix Contact |
| Product Type | Configurable Safety Module |
| Product | CABLE-25/8/250/PSR-M/001/R |
Phoenix Contact Adapter cable CABLE-25/8/250/PSR-M/001/R, 1574602 Technical Specifications
| Specification | Value |
|---|
| Note on application | Only for industrial use |
| Product type | Adapter cable |
| Safety Integrity Level (SIL) | Soldering on DSUB housing |
| Cable length | 2.5 m |
| Connection method | DSUB25 male/DSUB25 female |
| Ambient temperature (operation) | 30 ΓΒ°C ... 80 ΓΒ°C (for fixed installation) |
| Ambient temperature (storage/transport) | 30 ΓΒ°C ... 80 ΓΒ°C |
| Outer sheath, material | PVC |
| External sheath, color | green (RAL 6016) |
| Shielding | Plasticcoated aluminum foil, tinned copper braided shield |
| Cable resistance | Γ’ΒΒ€ 144 ΓΒ©/km (Loop) |
| Number of positions | 25 |
| Conductor material | Bare Cu litz wires |
| Cable cross section | 0.48 mmΓΒ² (AWG 26) |
