Pepperl Fuchs UBE800-F77-SE0-V31 Ultrasonic Sensor
The Pepperl Fuchs UBE800-F77-SE0-V31 Ultrasonic Sensor offers a 0 ... 800 mm emitter/receiver spacing sensing range, 1 switch output E0, NPN, NO output, and M8 x 1 connector , 4-pin connection. Manufactured by Pepperl Fuchs under the P&F Ultrasonic Sensor category, this model belongs to the through beam sensor.
| Brand | Pepperl Fuchs |
| Product Type | Ultrasonic Sensor |
| Model Number | UBE800-F77-SE0-V31 |
Pepperl Fuchs UBE800-F77-SE0-V31 Ultrasonic Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing range | 0 ... 800 mm emitter/receiver spacing |
| Standard target plate | see table |
| Transducer frequency | approx. 300 kHz |
| Response delay | β€ 5 ms |
| Permissible cable length | max. 300 m |
| LED green | Power on ( emitter ) |
| LED yellow | switching state ( receiver ) |
| Rated operating voltage | 24 V DC |
| Operating voltage | 20 ... 30 V DC , ripple 10 %SS; 12 ... 20 V DC sensitivity reduced to 80 % |
| No-load supply current | β€ 20 mA |
| Time delay before availability | β€ 150 ms |
| Input type | 1 program input (receiver) |
| Output type | 1 switch output E0, NPN, NO |
| Rated operating current | 200 mA , short-circuit/overload protected |
| Voltage drop | β€ 2 V |
| Switching frequency | 100 Hz |
| Ambient temperature | -25 ... 70 Β°C (-13 ... 158 Β°F) |
| Storage temperature | -40 ... 85 Β°C (-40 ... 185 Β°F) |
| Shock resistance | 30 g , 11 ms period |
| Vibration resistance | 10 ... 55 Hz , Amplitude Β± 1 mm |
| Connection type | M8 x 1 connector , 4-pin |
| Degree of protection | IP67 |
| Mass | per 10 g |
