Pepperl Fuchs UB2000-F42-E6-V15 Ultrasonic Sensor
The Pepperl Fuchs UB2000-F42-E6-V15 Ultrasonic Sensor offers a Rectangular design, 60 ... 2000 mm
sensing range, 2 switch outputs PNP, NO/NC selectable output, and Connector plug M12 x 1 , 5-pin connection. Manufactured by Pepperl Fuchs under the P&F Ultrasonic Sensor category, this model belongs to the diffuse reflective sensor.
| Brand | Pepperl Fuchs |
| Product Type | Ultrasonic Sensor |
| Model Number | UB2000-F42-E6-V15 |
Pepperl Fuchs UB2000-F42-E6-V15 Ultrasonic Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type of Sensing | Diffuse Reflective |
| Design | Rectangular |
| Sensing range | 60 ... 2000 mm |
| Adjustment range | 90 ... 2000 mm |
| Dead band | 0 ... 60 mm |
| Standard target plate | 100 mm x 100 mm |
| Transducer frequency | approx. 175 kHz |
| Response delay | approx. 150 ms |
| LED green | solid green: Power on |
| LED yellow 1 | solid: switching state switch output 1 flashing: program function |
| LED yellow 2 | solid: switching state switch output 2 flashing: program function |
| LED red | normal operation: "fault" program function: no object detected |
| Operating voltage | 10 ... 30 V DC , ripple 10 %SS |
| Output type | 2 switch outputs PNP, NO/NC selectable |
| Default setting | Switch point A1: 90 mm , Switch point A2: 2000 mm , wide sound lobe |
| Repeat accuracy | β€ 0.5 % of switching point |
| Switching frequency | β€ 2.7 Hz |
| Range hysteresis | 1 % of the set operating distance |
| Temperature influence | Β± 1 % of full-scale value |
| Standards | EN IEC 60947-5-2:2020 IEC 60947-5-2:2019 |
| UL approval | cULus Listed, Class 2 Power Source |
| CCC approval | CCC approval / marking not required for products rated β€36 V |
| Ambient temperature | -25 ... 70 Β°C (-13 ... 158 Β°F) |
| Storage temperature | -40 ... 85 Β°C (-40 ... 185 Β°F) |
| Connection type | Connector plug M12 x 1 , 5-pin |
| Degree of protection | IP54 |
| Material Housing | ABS |
IndMALL Automation Dealing offers P&F 2000mm Diffuse Reflective Sensor UB2000-F42-E6-V15 at unbeatable prices. The Main Technical Parameters of UB2000-F42-E6-V15 features Diffuse Reflective, Rectangular design with a sensing range of 60 ... 2000 mm
and an adjustment range of 90 ... 2000 mm
. It has a dead band of 0 ... 60 mm and uses a standard target plate of 100 mm x 100 mm. The transducer frequency is approximate approx. 175 kHz
, and the response delay of approx. 150 ms. Operating at 10 ... 30 V DC , ripple 10 %SS
, the sensor includes 2 switch outputs PNP, NO/NC selectable with default Switch point A1: 90 mm , Switch point A2: 2000 mm , wide sound lobe. It offers repeat accuracy of β€ 0.5 % of switching point, a switching frequency of β€ 2.7 Hz, range hysteresis of 1 % of the set operating distance, and a temperature influence of Β± 1 % of full-scale value. The sensor operates in ambient temperatures from -25 ... 70 Β°C (-13 ... 158 Β°F) and can be stored in temperatures from -40 ... 85 Β°C (-40 ... 185 Β°F). It feature Connector plug M12 x 1 , 5-pin, an IP54 protection rating, and an ABS housing. Take the First Step with a Quote for your P&F 2000mm Diffuse Reflective Sensor requirement. Choose us for unparalleled pricing and support over other Dealers & Distributors.
