Home Products Photoelectric Sensor Pepperl Fuchs RL31-54/115/136 Pepperl Fuchs RL31-54/115/136 Photoelectric Sensor The Pepperl Fuchs RL31-54/115/136 Photoelectric Sensor offers a 0 ... 9000 mm detection range, LED light source, and 2 m fixed cable connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the reflective sensor.
Brand Pepperl Fuchs Product Type Photoelectric Sensor Model Number RL31-54/115/136
Pepperl Fuchs RL31-54/115/136 Photoelectric Sensor β Technical Specifications Specification Value Effective detection range 0 ... 9000 mm Reflector distance 20 ... 9000 mm Threshold detection range 12 m Reference target reflector C110-2 Light source LED Light type modulated visible red light , 630 nm Polarization filter yes Diameter of the light spot approx. 200 mm at a distance of 6 m Opening angle 3 Β° Optical face - Control elements - Operating voltage 10 ... 30 V DC Ripple 10 % No-load supply current β€ 20 mA Switching type dark-on Signal output 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected Switching voltage max. 30 V DC Switching current max. 100 mA Voltage drop β€ 1.5 V Switching frequency β€ 500 Hz Response time β€ 1 ms Ambient temperature -30 ... 55 Β°C (-22 ... 131 Β°F) Storage temperature -40 ... 70 Β°C (-40 ... 158 Β°F) Degree of protection IP67 Connection 2 m fixed cable Mass 133 g Cable length -
