Pepperl Fuchs RL28-55/47/74 Photoelectric Sensor

Name: Pepperl Fuchs RL28-55/47/74
Brand: Pepperl Fuchs
SKU: RL28-55/47/74
Rating: 4 (4 reviews)

The Pepperl Fuchs RL28-55/47/74 Photoelectric Sensor offers a 0 ... 17 m detection range, LED light source, and connector M18, 4-pin connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the reflective sensor.

Datasheet

Brand	Pepperl Fuchs
Product Type	Photoelectric Sensor
Model Number	RL28-55/47/74

Pepperl Fuchs RL28-55/47/74 Photoelectric Sensor – Technical Specifications

Specification	Value
Effective detection range	0 ... 17 m
Reflector distance	0.05 ... 17 m
Threshold detection range	21 m
Reference target	H85-2 reflector
Light source	LED
Light type	modulated visible red light , 660 nm
Polarization filter	yes
Diameter of the light spot	approx. 290 mm at a distance of 17 m
Opening angle	emitter 1.2°receiver 2°
Optical face	-
Control elements	sensitivity adjustment (Adjustment to < 25% of the effective operating range) , Light-on/dark-on changeover switch
Operating voltage	10 ... 30 V DC
Ripple	10 %
No-load supply current	≤ 40 mA
Switching type	light/dark on switchable
Signal output	2 PNP, complementary, short-circuit protected, reverse polarity protected , open collectors
Switching voltage	max. 30 V DC
Switching current	max. 200 mA
Voltage drop	-
Switching frequency	1000 Hz
Response time	0.5 ms
Ambient temperature	-40 ... 60 °C (-40 ... 140 °F)
Storage temperature	-40 ... 60 °C (-40 ... 140 °F)
Degree of protection	IP67
Connection	connector M18, 4-pin
Mass	70 g
Cable length	-
