Pepperl Fuchs OJ500-M1K-E23 Fiber Optic Sensor
The Pepperl Fuchs OJ500-M1K-E23 Fiber Optic Sensor offers a up to 100 mm(LMR 18-3,2-1,0-K4) sensor range, modulated infrared light light type, and M16 terminal compartment, core cross section ≤ 2.5 mm2 connection. Manufactured by Pepperl Fuchs under the P&F Fiber Optic Sensor category.
| Brand | Pepperl Fuchs |
| Product Type | Fiber Optic Sensor |
| Model number | OJ500-M1K-E23 |
Pepperl Fuchs OJ500-M1K-E23 Fiber Optic Sensor – Technical Specifications
| Specification | Value |
|---|
| Sensor range | up to 100 mm(LMR 18-3,2-1,0-K4) |
| Detection range | up to 600 mm(LME 18-2,3-0,5-K3) |
| Light source | LED |
| Light type | modulated infrared light |
| Ambient light limit | 40000 Lux |
| Operation indicator | LED green |
| Function indicator | LED yellow: switching stateLED red: operating reserve (flashing) |
| Operating voltage | 10 ... 30 V DC |
| Switching type | light/dark on |
| Signal output | 1 PNP output, short-circuit protected, reverse polarity protected, open collector |
| Switching voltage | max. 30 V DC |
| Switching current | ≤ 200 mA |
| Voltage drop | - |
| Switching frequency | ≤ 1.5 kHz / 200 Hz switchable |
| Response time | ≤ 0.3 ms at 1.5 kHz ≤ 2.5 ms at 200 Hz |
| Repeat accuracy | - |
| Timer function | pulse extension 20 ms, switchable |
| Ambient temperature | -25 ... 70 °C (-13 ... 158 °F) |
| Storage temperature | -40 ... 80 °C (-40 ... 176 °F) |
| Degree of protection | IP67 |
| Connection | M16 terminal compartment, core cross section ≤ 2.5 mm2 |
| Mass | 100 g |
