Pepperl Fuchs OBT150-18GM40-E2-V1 Photoelectric Sensor

Name: Pepperl Fuchs OBT150-18GM40-E2-V1
Brand: Pepperl Fuchs
SKU: OBT150-18GM40-E2-V1
Rating: 4.3 (11 reviews)

The Pepperl Fuchs OBT150-18GM40-E2-V1 Photoelectric Sensor offers a 10 ... 150 mm detection range, LED light source, and 3-pin, M12 x 1 connector connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the diffuse mode sensor.

Datasheet

Brand	Pepperl Fuchs
Product Type	Photoelectric Sensor
Model Number	OBT150-18GM40-E2-V1

Pepperl Fuchs OBT150-18GM40-E2-V1 Photoelectric Sensor – Technical Specifications

Specification	Value
Detection range	10 ... 150 mm
Adjustment range	40 ... 150 mm
Reference target	standard white, 100 mm x 100 mm
Light source	LED
Light type	modulated visible red light
Polarization filter	-
Diameter of the light spot	approx. 6 mm at detection range 150 mm
Opening angle	approx. 2 °
Optical face	frontal
Operation indicator	LED green:on - power onflashing (4 Hz) - short circuit
Function indicator	LED yellow:constantly on - object detectedconstantly off - object not detected
Control elements	sensitivity adjustment
Operating voltage	10 ... 30 V DC
Ripple	max. 10 %
No-load supply current	< 25 mA
Switching type	Q - Pin4: PNP normally open / light-on
Signal output	1 PNP output, short-circuit protected, reverse polarity protected, open collector
Switching voltage	max. 30 V DC
Switching current	max. 100 mA , resistive load
Voltage drop	≤ 1.5 V DC
Switching frequency	500 Hz
Response time	≤ 1 ms
Ambient temperature	-40 ... 60 °C (-40 ... 140 °F)
Storage temperature	-40 ... 70 °C (-40 ... 158 °F)
Degree of protection	IP67
Connection	3-pin, M12 x 1 connector
Mass	approx. 15 g
Tightening torque, fastening screws	-
Detection range min.	10 ... 40 mm
Detection range max.	12 ... 150 mm
Background suppression	-
