Pepperl Fuchs OBR50M-R300-2PP-V1 Photoelectric Sensor
The Pepperl Fuchs OBR50M-R300-2PP-V1 Photoelectric Sensor offers a 0 ... 50 m detection range, LED light source, and 4-pin, M12 x 1 connector connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the reflective sensor.
| Brand | Pepperl Fuchs |
| Product Type | Photoelectric Sensor |
| Model Number | OBR50M-R300-2PP-V1 |
Pepperl Fuchs OBR50M-R300-2PP-V1 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Effective detection range | 0 ... 50 m |
| Reflector distance | 0.2 ... 50 m |
| Threshold detection range | - |
| Reference target | 3 x REF-H100 |
| Light source | LED |
| Light type | modulated visible red light |
| Polarization filter | - |
| Diameter of the light spot | approx. 16 cm x 18 cm at a distance of 10 m |
| Opening angle | - |
| Optical face | - |
| Control elements | Teach-In key |
| Operating voltage | 10 ... 30 V DC |
| Ripple | 10 % within the supply tolerance |
| No-load supply current | β€ 80 mA / 24 V DC |
| Switching type | Q - Pin4: NPN normally open / dark-on, PNP normally closed / light-on/Q - Pin2: NPN normally closed / light-on, PNP normally open / dark-on |
| Signal output | 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected |
| Switching voltage | max. 30 V DC |
| Switching current | max. 100 mA |
| Voltage drop | - |
| Switching frequency | 50 Hz |
| Response time | 5 ms |
| Ambient temperature | -40 ... 55 Β°C (-40 ... 131 Β°F) |
| Storage temperature | -40 ... 70 Β°C (-40 ... 158 Β°F) |
| Degree of protection | IP67 |
| Connection | 4-pin, M12 x 1 connector |
| Mass | 90 g |
| Cable length | - |
