Pepperl Fuchs OBE6000-12GM40-SE5-V1 Photoelectric Sensor

Name: Pepperl Fuchs OBE6000-12GM40-SE5-V1
Brand: Pepperl Fuchs
SKU: OBE6000-12GM40-SE5-V1
Rating: 4.3 (12 reviews)

The Pepperl Fuchs OBE6000-12GM40-SE5-V1 Photoelectric Sensor offers a 0 ... 6000 mm detection range, 1 PNP output, short-circuit protected, reverse polarity protected, open collector output, and 4-pin, M12 x 1 connector connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the through beam sensor.

Datasheet

Brand	Pepperl Fuchs
Product Type	Photoelectric Sensor
Model Number	OBE6000-12GM40-SE5-V1

Pepperl Fuchs OBE6000-12GM40-SE5-V1 Photoelectric Sensor – Technical Specifications

Specification	Value
Emitter	OBE6000-12GM40-V1
Receiver	OBE6000-12GM40-E5-V1
Effective detection range	0 ... 6000 mm
Threshold detection range	8500 mm
Light source	LED
Light type	red , 640 nm
Diameter of the light spot	approx. 800 mm at a distance of 6 m Red light
Opening angle	approx. 4
Optical face	PMMA
Operation indicator	LED green: Power on
Function indicator	LED yellow: lights up when receiving the light beam ; flashes when falling short of the operating reserve; OFF when light beam is interrupted
Control elements	sensitivity adjustment , receiver
Operating voltage	10 ... 30 V DC , class 2
Ripple	10 %
No-load supply current	≤ 30 mA (emitter and receiver)
Switching type	light/dark on electrically switchable
Signal output	1 PNP output, short-circuit protected, reverse polarity protected, open collector
Switching voltage	max. 30 V DC
Switching current	max. 100 mA
Voltage drop	≤ 2 V
Switching frequency	≤ 1000 Hz
Response time	0.5 ms
Ambient temperature	-30 ... 60 °C (-22 ... 140 °F)
Storage temperature	-40 ... 70 °C (-40 ... 158 °F)
Degree of protection	IP67
Connection	4-pin, M12 x 1 connector
Housing	brass, nickel-plated
Mass	approx. 15 g (device)
