Home Products Proximity Sensor Pepperl Fuchs NRN30-30GS50-E2-IO-V1 Pepperl Fuchs NRN30-30GS50-E2-IO-V1 Proximity Sensor The Pepperl Fuchs NRN30-30GS50-E2-IO-V1 Proximity Sensor offers a 30 mm (factory setting) operating distance, 3-wire, PNP, Normally open/closed (NO/NC) programmable, output, and non-flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
Brand Pepperl Fuchs Product Type Proximity Sensor Model Number NRN30-30GS50-E2-IO-V1
Pepperl Fuchs NRN30-30GS50-E2-IO-V1 Proximity Sensor β Technical Specifications Specification Value Switching function Normally open/closed (NO/NC) programmable Output type 3-wire, PNP Rated operating distance 30 mm (factory setting) Installation non-flush Assured operating distance 0 ... 24.3 mm Switching frequency 0 ... 680 Hz (switch point mode)0 ... 50 Hz (window mode, switch point mode with stability alarm) Hysteresis typ. 3 % Reverse polarity protection reverse polarity protected Short-circuit protection pulsing Ambient temperature -25 ... 70 Β°C (-13 ... 158 Β°F) Storage temperature -40 ... 85 Β°C (-40 ... 185 Β°F) Connection type Connector plug M12 x 1 , 4-pin Housing material Stainless steel 1.4305 / AISI 303 Sensing face PBT Degree of protection IP67 Mass 137 g
